TABLE OF CONTENTS
INSTALLATION                                1
Unpacking                   
          1
Placement                              1
Level Adjustment          
              1
Power Connection                        1
KEY FUNCTIONS             
                2
ANNUNCIATORS                              3
OPERATION    
                             4
Power Switch                     
      4
Display Backlight                         4
Weight Display                    
      4
Normal Unit Price                         4
Pre-pack Operation                   
   4
Tare Operation                          4
Price Look UP                      
    5
SCALE SETTINGS                             6
ERROR AND STATUS DISPLAYS                7
BEFORE YOU CALL SERVICE  
                7
CARE AND CLEANING                         7
SPECIFICATIONS
Display: 0.5” High Seven-Segment LCD with backlight
Weight = 6 Digits
Unit Weight = 6 Digits
Total Price = 6 Digits
Dimensions: 13.39" W x 13.39" D x 5.00" H
(340 mm x 340 mm x 127 mm)
Platform Size 12.60" W x 9.06" D
(320 mm x 230 mm)
Model
D15
D30
D60
Capacity and Division Value
15 lb x .005 lb (6 kg x .002 kg)
30 lb x .01 lb (15 kg .005 kg)
60 lb x .02 lb (30 kg .01 kg)
Zero Established on power up routine and maintained by
auto-zero circuitry
Power 12 VDC 1.0 A
Rechargeable battery pack or
AC Adapter 110/120 VAC 50/60Hz
Tare 100% of full scale capacity
Operating Temperature 32 ~ 104°F (0° ~ 40°C)
