Models using “Type Four” Models using “Type Five”
6550 6854DHR
6857DHR
6857KGDHR
“Type Four”
(8555-B517-08)
TRANSITION PLATE
“Type Five”
(1930-C199-08)
MOUNTING BASE
“Type Desk/Wall Mount”
(8555-B516-08)
DESKTOP PLATE
Models using “Desk/Wall Mount”
6500
BRW1000
CD-1000D
CR-500D
FHD-133-II
FHD-143-II
FHD-144-II
FHD-164-II
GP-400-MV1
GP-600-MV1
GP-600-RP
2.0”
WALL MOUNTING
Mount using two (2) #10
screws placed 2.00 inches
(51 mm) apart in the wall.
