Carefree Eclipse - Page 29

Carefree of Colorado Service Manual ECLIPSE
052547-301r7 27
GRAY
BROWN
YELLOW
RED
BLACK
132
GRAY
BROWN
YELLOW
132
5
6
RED
BLACK
5
6
Detail A
Optional Wall Mount 9-Pin Connector
4
798
65
1
32
4
798
65
1
32
Rear View of Connectors Shown
From
Exterior
Switch
From
Motor
From
Sensor
To
Patio Switch
Connector
To Motor
Connector
To
Control Box
Black
Red
Green
Black
Yellow
Red
Green
Yellow
Cables are 4-wire RJ11
terminated phone cord
(straight, no twist).
Detail B
Phone Cable
DR005b
Phone
Cable
Phone
Cable
N
OTES:
1
Splitter is used only when the optional Lock-Out Sensor is installed. Connect the RF
receiver directly to the control box if Lock-Out is not installed.
2
The optional Lock-Out Sensor can only be used with control boxes marked "p/n 060574-
003". Wires for the sensor are not pin specific.
3
Early versions of the Eclipse Exterior Switch cable may have different wire colors.
Current Color Previous Color
Black or White Gray Jacket Color:
Brown Black1
Gray Black2 Wire Colors:
Yellow Yellow/Green
4
Early versions of the Patio Switch harness may have different wire colors.
Current Color Previous Color
Brown Black
Gray Red
Yellow Blue
