ECLIPSE Service Manual Carefree of Colorado
14 052547-301r7
DIAGNOSTICS
The following procedures are intended to aid the service technician to logically resolve operational issues
with the mechanical and standard electronics installations.
Common Operational Items
The following items are operational items that may come up as questions during normal operation. These
are also given in the operator's manual.
1. The motor has a thermal protection circuit. If the motor overheats, the circuit will shut off the motor.
Wait approximately 15 minutes, operation will return to normal. As an example, this may occur if the
awning is fully closed and retract switch pushed repeatedly, then the awning does not extend.
2. The awning seems to extend and retract slowly. The operational range is 28-35 seconds to extend or
retract. If the power supply is on the low side of the range (10V) the awning will move slower.
3. The awning may appear to move jerkily. When the fabric is rolled out, the Alumaguard or Uniguard
may "bounce" creating a wave like motion in the canopy fabric. This will create the appearance of
moving jerkily.
4. With Uniguard, the awning sticks or hangs up. When Uniguard is installed with a vinyl canopy, the vinyl
will have a tendency to "cling" to the Uniguard when not used over an extended period. Open and
close the awning in short bursts 2 or 3 times, the awning will then open normally.
Refer to the appropriate wiring diagram for the system being tested:
S
TANDARD ELECTRICAL
Wiring diagram – single switch page 23
Wiring diagr
am – multiple switch page 23
A
UTO RETRACT SYSTEMS:
Wiring diagram – Windsmart page 25
Wiring diagr
am – Direct Response page 26
Procedures in this section: Page
STANDARD ELECTRICAL................................................................................................................... 15
D01 THE AWNING OPERATES IN REVERSE OF THE SWITCH PLATE ...................................................15
D02 T
HE AWNING DOES NOT EXTEND AND/OR RETRACT .................................................................15
D03 A
RM DOES NOT EXTEND OR DOES NOT EXTEND COMPLETELY .................................................17
AUTO RETRACT SYSTEMS ................................................................................................................ 18
D04 THE AWNING OPERATES IN REVERSE OF THE SWITCH PLATE MARKINGS ..................................18
D05 T
HE AWNING DOES NOT EXTEND AND/OR RETRACT USING THE PATIO SWITCH.........................18
D06
A AWNING DOES NOT AUTO-RETRACT DURING WINDY CONDITIONS -WINDSMART.....................19
D06
B AWNING DOES NOT AUTO-RETRACT DURING WINDY CONDITIONS –DIRECT RESPONSE..........19
D07 A
WNING DOES NOT MOVE WHEN KEY FOB BUTTONS ARE PUSHED...........................................20
COMMON TEST PROCEDURES........................................................................................................... 21
CT01 TESTING A SWITCH AND HARNESS .........................................................................................21
CT02 T
ESTING THE CONTROL BOX .................................................................................................22
CT03 T
ESTING THE BATTERY AND CHARGER ..................................................................................22
