D06A AWNING DOES NOT AUTO-RETRACT DURING WINDY CONDITIONS -WINDSMART
NOTE: The mode switch must be set to Auto-Retract ON.
YES
Function works using the switch; go
to test B
A
Confirm that the retract function works using the
EXTEND/RETRACT switch
NO
Function does not work with switch;
go to procedure D01 on page 17
Test Anemometer
YES
Go to step B2
1. Do the anemometer cups spin freely?
NO
Anemometer defective - replace
YES
Plug the connector into the control
box; Go to “Testing The Control Box”
2. Test signal from anemometer:
2.1. Remove anemometer connector from control box;
2.2. Place an ohmmeter between pins of connector;
2.3. Have a helper SLOWLY turn the anemometer: Does
the circuit open and close? It should open and close
once for every revolution. When closed, the meter
should read approximately 1000ohms
NO
The circuit stays open or stays closed
or the ohmmeter reads more that
1000ohms (2x or more); go to step
B3
YES
Continuity OK; replace anemometer
B
3. Test the wire continuity between the connector and the
anemometer.
NO
Repair or Replace wires as required
D06B AWNING DOES NOT AUTO-RETRACT DURING WINDY CONDITIONS –DIRECT RESPONSE
NOTE: For series I switches, the Mode switch must be in the POWER ON or AUTO-RETRACT ON positions for the
key FOB to work. For series III switches, the On/Off switch must be ON.
YES
Function works using the switch; go
to test B
A
Confirm that the retract function works using the
EXTEND/RETRACT switch
NO
Function does not work with switch;
go to procedure D01
Test Motion Sensor
NOTE: A sensor tester is now available from Carefree. Follow the instructions included with the tester. or
Follow the steps below.
YES
Go to step 2
1. Confirm cable is plugged into connector on box marked
“Motion Sensor”
NO
Correct as required and test.
YES
Wired OK, go to step 3
2. Remove cable from box and inspect connector on cable.
Connector should be wired as shown in the wiring diagram
(page 23 or page 24).
NO
Remove connector and replace
YES
Awning retracts; original sensor
defective - replace
B
3. Unplug sensor from control box
3.1. Connect a second sensor into control box.
3.2. Set the control switches for the auto retract function
3.3. Hold the second sensor vertically and gently move up
and down.
NO
Awning does not retract; control box
defective - replace
To Next Page
