Carefree of Colorado Service Manual ECLIPSE
052547-301r7 31
Black
Red
Green
Black
Yellow
Red
Green
Yellow
Cables are 4-wire RJ11
terminated phone cord
(straight, no twist).
3 2 1
312
645
978
12 1011
15 1314
C1
C2
Power
3 2 1
3
4
5
6
7
8
9
10
11
12
13
14
15
1 2
2 1
C4
Patio Switch
2 31 2 31
C5
Windspeed Switch
2 1
C3
Motor
(1) (2)
WHITE
BLUE
BLACK
BLACK
GREEN
YELLOW
RED
BLUE
BLACK
RED
YELLOW
GREY
BROWN
BLACK
RED
C15
DR Sensor
C16
RF Receiver &
Lock Out Sensor
3 2 1
Carefree of Colorado
12V DIRECT RESPONSE
CONTROL BOX
PART NO. 060574-003
TO EYE PORT on RP24 Program Mode
Press to Learn Transmitter
UP
RF Reciever
Control
Box
4
3
2
1
3 2 1
Splitter
(ref)
Lock Out Sensor(ref)
C1
C2
C3
C16
C15
C4
C5
C7
Splitter
Lock Out
Sensor
Carefree Harness
DR031b
#6 x 1/2” Screw
qty: 2
#6 x 1/2” Screw
qty: 2
6” Cable
Phone Cable
DETAIL
B
2 1
2 1
C6
C6
