Carefree of Colorado Service Manual ECLIPSE
052547-301r7 37
Item Part Number Description
Notes
1
1/2 Set Hardware, Arm Assy, Motorized, RH Standard 3
1/2 Set Hardware, Arm Assy, Motorized, RH XL 3
2
1/2 Set Hardware, Arm Assy, Idler, RH Standard 3
Contact Carefree
for Order
Information
1/2 Set Hardware, Arm Assy, Idler, RH XL 3
3
R001099 Gas Shock
4
R001100XXX Cap, Rail Top
5
R014635XXX Top Extension Kit (aftermarket installations only) 4
5a
R001094XXX Top Mounting Bracket (aftermarket installation only)
6
R001102XXX Fascia
R001102XXX-XL Fascia for XL
7
R001103XXX Fascia Cap, No Switch
8
NLA Fascia Cap, External Switch (Direct Wire)
9
NLA Fascia Cap, External Switch (Battery Configuration Only)
10
R001101 Hinge Bracket Kit
11
R019291-005 Arm Roller Kit White
R019291-006 Arm Roller Kit Black
12
901008 Rubber Bumper
13
R001110XXX Cap, Channel, Bottom
14
R001111XXX Cap, Channel, Top
15
R001104XXX Motor Assy
16
R001323 Kit, Head Attach Hardware
17
R060414-00X Motor Cable
18
R001324XXX Kit, Motor Cover 2
19
R001107XXX Idler Assy Standard
20
R001148XXX Idler Assy XL
21
R001325XXX Kit, Idler Cover 2
22a
19xx00 Roller Tube, 3-Slot 3 1/2" Dia
22b
15xx00A Roller Tube, w/ Utility Slot 3 1/2" Dia
23
Canopy Refer to Canopy Order Form
24
20xxx36XXX Alumaguard Assembly Only
25
R001247XXX-xxx Soft Connect 4.25 Wide
R001247XXX-xxxT Soft Connect 5.25" Wide
26
R001247XXX-xxx Soft Connect 4.25 Wide
27
R00928 Tractioner Kit pkg of 2
R001509 Owners Kit: Jumper Cable, Manual & Hex Key not shown
041223-006 Foam Tape, Black not shown
041223-005 Foam Tape, White not shown
NOTES:
1. XXX = Color; xxx = Length in inches.
2. Cover kits include front cover, rear cover and attaching screws.
3. After 01-01-2011 all replacement arms will have a 60 7/8" rear extrusion. Aftermarket arms will include
item 5 (top extension kit). This change does not affect existing mounting hole locations.
4. Top extension kit (item 5) includes top mounting bracket (item 5a)
