Carefree of Colorado Service Manual ECLIPSE
052547-301r7 39
Item
Part Number Description Notes
1
R001605 Kit, Single Switch
2
R001112 Relay Module Multi-Switch
3
R019468-006 Kit, Multiple Switch Multi Switch
4
R001147 Receptacle Multi-Switch
5
R001098 Battery Battery Configuration Only
6
NLA Battery Clip set of 2
7
R001097 Battery Charger Battery Configuration Only
8
NLA Fascia Cap, External Switch (Battery Configuration Only)
9
R019489-001 Switch Kit, Direct Response 9
10
R060345-001 Harness - Power, Motor Connect
11
R060574-003 Controller 2, 3, 6
12
R060538-002 Sensor w/ Cable
13
R040562-001 Cord Retainer
14
R060434-001 Phone Cable, 60”
15
R060532-001 Ignition Lockout Sensor, EL 5
16
R060589-001 Splitter Used with Ignition Lockout
17
SR0095 Sensor Test Tool
18
R001036 RF Remote Receiver, 418 MHz 4
19
R060429-002 RF Remote Receiver, 433 MHz, Version 2 4
20
R060430-003 Key FOB, Remote, 418 MHz 4
21
Obsolete Key FOB, Remote, 433 MHz, Version 1 4
22
R060622-001 Key FOB, Remote, 433 MHZ, Version 2 4
NOTES:
1. Windsmart has been discontinued in 2007 and not available for original or upgrade installations.
Components are no longer available.
2. Control Boxes for the WindSmart and Direct Response are NOT interchangeable.
3. A Direct Response upgrade kit (p/n SR0036) is available and contains items 9 thru 14.
4. Key FOB and Receiver must match in frequency (418 MHz or 433 MHz). 418 MHz receivers are
marked "RR24" and have a blue band or no band around the antenna. 433 MHz receivers are
marked "RR" and have a red band around the antenna. Refer to the "Operational Notes" on
page 28 for application differences between "Version 1" and "Version 2" remotes and receivers.
5. The optional Ignition Lockout Sensor can only be used with controller boxes (item 11) that are
marked with 060574-003. Sensor does not work with boxes marked with -001 or -002.
6. The controller box (item 11) marked with 060574-003 is backward compatible and can be used
for replacement of all previous versions marked with -001 and -002.
7. Switch kit (item 1) includes switch, faceplates, screws and connector and replaces all previous
single switch kits. Components not available separately.
8. Switch kit (item 3) includes switches, faceplate and screws and replaces all previous multi switch kits.
Components not available separately.
9. Switch kit (item 9) includes switches w/ harnesses, faceplate and screws and replaces all previous multi
switch kits for direct response. Components not available separately.
