1.3 BMS bus options
Optically isolated 485 PCOS004850 + plastic part PCOS00S030
LonWorks FTT10 (*) PCO10000F0 + plastic part PCOS00S030
LonWorks FTT10 standard chiller profi le (*) PCO10001F0 + plastic part PCOS00S030
BACNET IP/Ethernet connection PCO1000WB0 + plastic part PCOS00S020
BACNET MSTP RS485 connection PCO1000BA0
+ plastic part PCOS00S020
(*) Please to use option card produced starting from february 2011 that wrote rev. 2 on the package.
1.4 Connector kit
Medium version plug-in screw UPCCONN0M0
Small version plug-in screw UPCCONN0S0
2. TECHNICAL SPECIFICATIONS
2.1 Mechanical specifi cations
dimensions • SMALL version fi tted on 10 DIN rail modules, 175 x 113 x 55 mm
• MEDIUM version fi tted on 13 DIN rail modules, 228 x 113 x 55 mm
installation DIN rail
2.2 Plastic case
• fi tted on DIN rail according to DIN 43880 and CEI EN 50022 standards;
• material: technopolymer;
• fl ame retardancy: V2 (UL94) and 850 °C (IEC 695);
• ball pressure test: 125 °C;
• resistance to creeping current: ≥250 V;
• colour: grey RAL7035
