Carel μPC - 3 Dimensioni

9
+050001570 - 1.2 - 22.06.11
ITA
3. DIMENSIONI
Modello Small (mm)
107.44
5.08
62.58
170.08
5.08
5.08
5.08
5.08
Ø 4 mm
55
40
175
113
230 Vac
(with
transformer)
24 Vac
(without
transformer)
Fig. 3.a
Modello Medium (mm)
107
9.08
54.15
111.5
219
5.08
5.08
5.08
19.86
5.08
213.92
Ø 4
228
113
5540
230 Vac
(with
transformer)
24 Vac
(without
transformer)
Fig. 3.b
