Carestream Focus 35C - Product Specifications

Overview
2–6 AJ4309 | 2019-08-13
Product Specifications
Detector
Item Specifications
Model Focus 35C
Image Sensor a-Si (amorphous silicon) TFT
Pixel Size 150 μm
Active Array 2304 x 2800
Active Area (H x V) 345.6 x 420.0 mm (13.6 x 16.5 in.)
Gray Scales 16 bit
Spatial Resolution 3.3 Lp/mm
Image Acquisition Time (Wireless)
Both AP Mode and Client Mode
Preview acquisition time: 3 sec.
Processed acquisition time: 5 sec.
Cycle Time Min. 8 sec.
Power Consumption Max. 18 W
Dimension (L × W × H) 460.0 x 384.0 x 15.0 mm (18.1 x 15.1 x
0.6 in.)
Weight (with one battery) 3.43 kg (7.56 lb)
Image Transfer Wireless: IEEE802.11a/b/g/n/ac
Data Transmission Rate (Wireless) 802.11b: Max. 11 Mbps
802.11a/g: Max. 54 Mbps
802.11n: Max. 300 Mbps (MIMO 2 x 2)
802.11ac: Max. 867 Mbps(MIMO 2 x 2)
