Overview
2–12 AJ4309 | 2019-08-13
Intended Information Flow
The detector sends the acquired image data to the workstation. The workstation sends
the user's commands to the detector. Please refer to the operation manual of the console
for detail.
Hazardous Situations Resulting From Failure of the IT-network
• Failure of completing essential performance
• Failure of finishing configuration of product
• Incompatibility of operating system
• Failure of change or update to software
• Compatibility of interface
• Data transfer protocol error
• Inconsistency of interface or format leads to data distortion
• Data output failed
Warning
Connection of the main unit to an IT network that includes other equipment could result
in previously unidentified risks.
The manufacturer of the x-ray machine should identify, analyze, evaluate, and control
these risks; subsequent changes to the IT-network could introduce new risks and require
additional analysis.
Changes to the IT Network
• Changes in the IT network configuration
Data Transmission Rate 802.11b: Max. 11 Mbps
802.11a/g: Max. 54 Mbps
802.11n: Max. 300 Mbps (MIMO 2x2)
802.11ac: Max. 867 Mbps (MIMO 2x2)
Modulation 802.11b: CCK, DQPSK, DBPSK
802.11a/g/n: 64 QAM, 16 QAM, QPSK, BPSK
802.11ac: 256 QAM, 64 QAM, 16 QAM, QPSK, BPSK
Security WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64 bit, and 128 bit
Item Specifications
To Next Page
