STEAM 2 GR.
Display NO NO
Maximum quantity of coffee dispensed per hour 240 480
Width (mm.) 306 577
Height (mm.) 498 498
Depth (mm.) 476 476
Net weight (Kg.) 32 45
Boiler capacity (lt.) 4 11
Hot water nozzle 1 1
Steam nozzle 1 2
Automatic cappuccino LM maker optional 1 1+1
Boiler resistor (W) Standard version 1600 2700
Voltage 220-240V 1N 50/60 Hz
200V 1N 50/60 Hz
120V 1N 50/60 Hz
220-240V 1N 50/60 Hz
200V 1N 50/60 Hz
Materials used:
Copper for boiler and piping
reinforced silicone for the articulated feed tube
reinforced silicone for the articulated pump tube
brass chromed for the brewing group
brass for taps and connections
Working area in stainless steel for Pratica, painted stainless for Pratica Double steam.
Peripheral applications: serial connection RS232C for I/O interface 18/26 relay
NOTE: The registration and technical data plate of the machine is on the side of the machine behind the drip tray.
