Carlisle BINKS E4-100 - Page 12

EN
2
192029
12

7 195646 1INLET MANIFOLD
2" EXTENDED 90° ELBOW
5 194930 3 102.1mm (UNEQUAL)
6 194931 1 315.1mm (UNEQUAL)
195647
2" EXTENDED 90° ELBOW
Service Manual
77-3243
195670 PRV and Manifold Assembly - PARTS LIST
ITEM PART NO. DESCRIPTION QTY REMARKS
4
3
192544
12
104253-E41 1PRV ASSEMBLY - 22 BAR
OUTLET MANIFOLD 18
2'' SANITARY CLAMP
2'' SANITARY GASKET
192791
2" STANDARD 90° ELBOW 2
88.9mm (EQUAL)
KEY
(Reverse for assembly)
LOCTITE
TORQUE
MAINTENANCE ORDER
GREASE INTERNAL
(AGMD-010)
GREASE
77-3330 R1.3 12/36 www.carlisleft.com
