Fluid Output @ 20 HZ [10 cycles/min]
Synthetic Oil
* NOTE
Pressure when used in 'Smart Mode' (Closed Loop Pressure Mode)
Reduce Maximum working pressure by 2 bar [29 psi] when using in Open Loop Flow Mode
e.g. E4-100 Maximum Set Pressure of 18 bar to operate Pump on a 24/7 basis
'B' Fluid outlet connection:
2'' NOTE
460V 3PH 5.0 Hp @ 60HZ
e.g. E4-100 Maximum Set Pressure of 18 bar to
operate Pump on a 24/7 basis
Class 1, Group D. 505 kg [1110 lbs]
AC Induction Electric Motor - USA Model
Reduce Maximum working pressure by 2 bar [29
psi] when using in Open Loop Flow Mode
Nominal pump stroke:
25 l/m [6.5 US gal/m]
Fluid Output @ 80 HZ [40 cycles/min] 100 l/m [26 US gal/m]
2.5 l/m [0.65 US gal/m]
EN
Specification
Gearbox Ratio: 56:1
* E4-100 Maximum fluid pressure:
E4-100 Nominal Flow Volume / Cycle:
'A' Fluid inlet connection:
60mm [2.36 ins]
Rated 20 to 80 Hz (c/w thermisters) 2 bar [29 psi]
20bar [290psi]
77-3330 R1.3 4/36 www.carlisleft.com
