EN
Acceleration Ramp
Deceleration Ramp
Rated Motor Power 3.7 kW (5 HP)
Rated Motor Current 6.2 A
Rated Motor Power Factor 0.835
Rated Motor Efficiency 90.2
Rated Motor Frequency 60 Hz
Rated Motor Voltage 460 V
0.1 Seconds
5 Seconds
Rated Motor Speed 1755 RPM
INSTALLATION
Required Inverter Settings Value
Maximum Hz Output 80 Hz
Mininmum Hz Output 20 Hz
Electric Motor
Inverter
The motor must be wired to provide a clockwise direction of the cam.
Electric Motors for hazardous areas are specially designed to comply with official regulations concerning the risk
of explosion.
If improperly used, badly connected, or altered no matter how minor, their reliability could be in doubt.
Standards relating to the connection and use of electrical apparatus in hazardous areas must be taken into
consideration.
Only trained personnel familiar with these standards should handle this type of apparatus.
The motor is fitted with PTC temperature sensors (Thermistors).
Once operating temperature is reached, this device quickly changes the resistance; it must be connected to a
suitable releasing device mounted within the control panel and wired to stop the motor if an over temperature
occurs.
77-3330 R1.3 7/36 www.carlisleft.com
