SERVICE AND TROUBLESHOOTING
Scan QR codes below for links to service and troubleshooting
information for the 06CC compressors.
TORQUE SPECIFICATIONS
020-611 06D/E/CC Pocket Service Guide
https://bit.ly/36bz6ku
574-018 Failure Modes and Troubleshooting Guide
https://bit.ly/3CBaDkM
06-009 06CC Service Parts List
https://bit.ly/3buR04B
Table 6 — Fastener Torque Specifications
THREAD SIZE TORQUE RANGE APPLICATION
No. 10-24
1-2 ft-lb
(1.4-2.7 Nm)
Terminal Box Cover Screws
7/16-20 UNF
8-14 ft-lb
(11-19 Nm)
Oil Drain SAE Plug
1/4-18 NPT
20-30 ft-lb max
(27-41 Nm)
Pipe Plug, Gauge Connection
1/4-28 UNF
3-5 ft-lb
(4-7 Nm)
Oil Sightglass
Terminal Box
3/8-16 UNC
18 ft-lb max
(24 Nm)
Terminal Post Jam Nut No. 3 (Top)
Finger Tight Terminal Post Jam Nut No. 2 (Middle)
Do Not Disturb Terminal Post Jam Nut No. 1 (Bottom)
30-50 ft-lb
(41-68 Nm)
Crankcase Mounting Bolt
1/2-13 UNC
80-90 ft-lb
(108-122 Nm)
Suction Service Valve (4-Bolt)
3/4-16 UNF
44-55 ft-lb
(60-75 Nm)
OPSS Sensor
