Carlyle 06T 033 Series User Manual

19
OIL CARTRIDGE FILTER ELEMENT
8.25"
END CAP, 1.75" O.D.
CENTER CORE,
PERFORATED
3u FIBERGLASS
SUPPORTED
(209.6cm)
(44.5cm)
1.75" (44.5cm) O.D. X 1.00" (25.4cm)
I.D. W/O–RING GROOVE
1.00"
(25.4cm)
1.75"
(44.5cm)
O–RING, 0.975" (24.8cm) I.D. X
0.210" (5.3cm) CROSS SECT.
END CAP,
INLET I.D.
0.876/0.880
(22.23/22.35)
X 0.75 (19.1) DEEP
2 5/16" - 16 UNC
THREADED O-RING
CLOSURE
2.62 O.D.
(66.6)
DRAIN
1/4"-3000# NPT
HALF COUPLING
(PLUGGED)
8.56
±0.06
(217.4)
10.00
±0.06
(254.0)
5.25
±0.06
(133.4)
3.25
(82.6)
3.25
(82.6)
FILTER HOUSING REPLACEMENT TYPE
FOR REFERENCE ONLY
INCHES
[MILLIMETERS (mm)]
FOR REFERENCE ONLY
INCHES
[CENTIMETERS (cm)]
