16
the module will automatically reset.
ALARM
Sensor Failure
If at any point the module detects a failure of an input device (thermistor,
pressure transducer), the module will initiate a shutdown sequence.
Motor Thermistor Failure
Discharge Thermistor Failure
Suction Pressure Transducer Failure
Oil Pressure Sensor Failure
Discharge Pressure Sensor Failure
Alarm
Code
1-1
1-2
1-3
1-4
1-5
Manual
Reset
No
No
No
No
No
Alarm Code Summary
Following is a summary of the diagnostic alarm codes flashed by the yellow alarm light
during a compressor alarm.
DIAGNOSTIC CODES
CODE Definition
1 Reverse Rotation
2 Safety Circuit Open
3 Change Oil Filter
4 Low Oil Differential
5 High Discharge Temperature
6 High Motor Temperature
7 Compressor Unloading
1-1 Motor Thermistor Failure
1-2 Discharge Thermistor Failure
1-3 Suction Press Sensor Failure
1-4 Oil Pressure Sensor Failure
1-5 Discharge Press Sensor Failure
Notes:
- The alarm code is flashed out by the amber alarm lamp
- A pause is present after each code is flashed out
- The sensor failure codes (1-1:1-5) are preceded by a long
steady lamp to distinguish them from the other alarm codes
