INSTALLATION cont.
Control System
The control system is comprised of a 1/16 DIN temperature controller. The drawing below shows
the control panel (exact controller may vary). The display panel consists of a power switch,
refrigeration switch, and a temperature controller. The temperature controller’s unit is degrees
Celsius (
°
C). Refer to the figure below for the layout for the indicator lights as detailed below.
See appendix for controller operating instructions.
2 0
.
CONTROL PANEL
