Drain connection
Connect a 3/8” NPT drain line to the drain connection located on the lower back side of the chamber. The figure
below shows the drain connection on the back of the chamber. For proper operation the drain hose should not be
kinked or bent. It should run down from the chamber and go into an open floor drain.
Models 6030, 6031, 6032
Right side of chamber
Models 6010, 6011, 6012
Back side of chamber
Power
PLEASE READ CAREFULLY!
For personal safety, this chamber must be properly grounded.
The Power Cord of this chamber is equipped with a grounded plug which mates with a
corresponding outlet to minimize the possibility of electrical shock from the chamber. CARON
recommends that the chamber have a dedicated wall outlet.
Models 6030, 6031, 6032
Models 6010, 6011, 6012
