11
2297
A
500
500
1830
1830
B
4
1
1
4
2
2
1351
500
500
230
2254
B
4
1
1
4
2
2
1830
230
1830
3
2254
C1
C2
Standard units
5994 2850 621 2662
6909 2850 621 2662
7824 2050 1036 3578
8739 1150 1951 4493
NOTE: Refer to the certified dimensional drawings
supplied with the unit, when designing an installation.
Units with low and very low noise levels
All dimensions are in mm.
Clearances required for operation and maintenance
Clearances required for tube removal
Thickness of sound absorption kit
Clearances required for maintenance and air ow
Water inlet
Water outlet
Power supply
Air outlet - do not obstruct
1
2
3
4
