PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDR030 / 40QAC036
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
640/0.02 740/0.02 840/0.03
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 29.0 31.4 33.0 34.1 29.8 31.8 33.2 34.2 30.6 32.0 33.4 34.3
SHG 28.0 25.8 21.4 17.1 28.5 26.5 21.9 17.3 30.6 27.4 22.2 17.5
TC 28.2 30.6 32.2 33.3 29.1 31.1 32.5 33.5 29.8 31.3 32.6 33.6
kW 1.57 1.57 1.58 1.58 1.56 1.57 1.58 1.58 1.57 1.58 1.59 1.58
CMP 1.22 1.22 1.23 1.23 1.21 1.22 1.23 1.23 1.22 1.23 1.24 1.23
LDB 47.4 50.3 55.8 61.2 49.9 52.3 57.6 62.8 50.4 53.7 59.2 64.1
LWB 42.0 47.3 53.3 59.5 43.1 48.7 54.6 60.8 44.1 49.9 55.8 61.8
65
(18.3)
TCG 28.6 30.9 33.1 34.4 29.3 31.4 33.3 34.6 30.2 31.9 33.6 34.8
SHG 27.5 26.0 21.8 17.6 29.3 27.1 22.5 17.8 30.2 28.1 23.2 18.0
TC 27.8 30.2 32.3 33.7 28.6 30.7 32.5 33.9 29.4 31.1 32.8 34.0
kW 1.74 1.74 1.74 1.76 1.73 1.74 1.75 1.76 1.74 1.74 1.75 1.76
CMP 1.39 1.39 1.39 1.41 1.38 1.39 1.40 1.41 1.39 1.39 1.40 1.41
LDB 48.0 50.1 55.4 60.7 49.0 51.6 56.9 62.2 50.8 53.1 58.2 63.5
LWB 42.3 47.6 53.2 59.3 43.4 48.9 54.6 60.6 44.3 49.9 55.7 61.6
75
(23.9)
TCG 27.7 29.9 32.5 34.6 28.6 30.5 33.0 34.8 29.5 30.9 33.4 34.9
SHG 27.7 25.6 21.9 17.7 28.6 26.9 22.7 18.1 29.5 28.1 23.5 18.5
TC 26.9 29.2 31.8 33.8 27.9 29.7 32.2 34.1 28.8 30.2 32.6 34.2
kW 1.92 1.93 1.93 1.95 1.93 1.93 1.93 1.95 1.93 1.94 1.93 1.96
CMP 1.57 1.58 1.58 1.60 1.58 1.58 1.58 1.60 1.58 1.59 1.58 1.61
LDB 47.8 50.5 55.3 60.6 49.7 51.9 56.7 61.9 51.4 53.1 57.9 63.1
LWB 42.8 48.1 53.5 59.3 43.8 49.3 54.7 60.5 44.6 50.3 55.8 61.6
85
(29.4)
TCG 26.7 28.7 31.4 33.9 27.7 29.2 31.9 34.2 28.5 29.7 32.3 34.4
SHG 26.7 24.9 21.6 17.5 27.7 26.3 22.4 18.0 28.5 27.5 23.3 18.5
TC 26.0 28.0 30.7 33.1 26.9 28.4 31.2 33.5 27.8 28.9 31.6 33.7
kW 2.12 2.14 2.16 2.17 2.13 2.15 2.16 2.17 2.15 2.15 2.16 2.17
CMP 1.77 1.79 1.81 1.82 1.78 1.80 1.81 1.82 1.80 1.80 1.81 1.82
LDB 48.9 51.3 55.6 60.7 50.8 52.5 57.0 62.0 52.5 53.6 58.1 63.0
LWB 43.4 48.8 54.0 59.6 44.3 50.0 55.2 60.7 45.1 50.9 56.1 61.7
95
(35)
TCG 25.6 27.2 28.9 32.9 26.5 27.7 29.5 33.3 27.3 28.1 29.8 33.6
SHG 25.6 24.0 20.1 17.3 26.5 25.4 21.1 17.8 27.3 26.5 22.8 18.3
TC 24.8 26.4 28.2 32.1 25.7 26.9 28.7 32.5 26.6 27.3 29.0 32.8
kW 2.34 2.36 2.39 2.40 2.35 2.37 2.40 2.42 2.38 2.37 2.42 2.42
CMP 1.99 2.01 2.04 2.05 2.00 2.02 2.05 2.07 2.03 2.02 2.07 2.07
LDB 50.3 52.3 56.4 61.0 52.1 53.5 57.5 62.2 53.6 54.6 58.5 63.3
LWB 44.0 49.6 54.6 60.0 44.9 50.7 55.8 61.1 45.7 51.6 56.7 62.0
105
(40.6)
TCG 24.3 25.5 28.4 31.4 25.1 25.9 28.9 31.8 25.9 26.4 29.3 32.2
SHG 24.3 23.2 20.1 16.8 25.1 24.4 21.2 17.4 25.9 25.6 22.1 18.0
TC 23.5 24.7 27.7 30.7 24.4 25.2 28.1 31.1 25.2 25.6 28.5 31.5
kW 2.59 2.60 2.64 2.67 2.59 2.60 2.65 2.67 2.60 2.61 2.65 2.68
CMP 2.24 2.25 2.29 2.32 2.24 2.25 2.30 2.32 2.25 2.26 2.30 2.33
LDB 51.8 53.3 57.3 61.6 53.5 54.5 58.3 62.6 55.0 55.5 59.2 63.6
LWB 44.8 50.5 55.5 60.6 45.6 51.5 56.5 61.6 46.3 52.3 57.3 62.5
115
(46.1)
TCG 22.8 23.5 26.4 29.7 23.7 24.4 26.9 30.1 24.4 24.9 27.2 30.4
SHG 22.8 22.3 19.2 16.1 23.7 22.6 20.2 16.8 24.4 23.4 21.1 17.4
TC 22.1 22.8 25.7 28.9 22.9 23.7 26.1 29.3 23.6 24.2 26.5 29.7
kW 2.83 2.85 2.89 2.95 2.86 2.86 2.90 2.96 2.86 2.87 2.91 2.97
CMP 2.48 2.50 2.54 2.60 2.51 2.51 2.55 2.61 2.51 2.52 2.56 2.62
LDB 53.6 54.4 58.4 62.3 55.1 56.4 59.3 63.2 56.6 57.7 60.1 64.1
LWB 45.6 51.5 56.4 61.3 46.4 52.2 57.3 62.3 47.0 52.9 58.1 63.1
125
(51.7)
TCG 21.2 21.7 24.1 27.4 22.0 22.2 24.5 27.8 22.7 22.7 24.9 28.1
SHG 21.2 20.6 18.1 15.1 22.0 21.6 19.1 15.8 22.7 22.7 20.1 16.5
TC 20.5 21.0 23.4 26.6 21.3 21.4 23.8 27.1 22.0 21.9 24.1 27.3
kW 3.12 3.12 3.17 3.24 3.14 3.14 3.18 3.25 3.16 3.15 3.19 3.26
CMP 2.77 2.77 2.82 2.89 2.79 2.79 2.83 2.90 2.81 2.80 2.84 2.91
LDB 55.5 56.4 59.6 63.4 56.9 57.5 60.4 64.3 58.2 58.4 61.2 65.0
LWB 46.5 52.4 57.4 62.3 47.2 53.2 58.2 63.1 47.8 53.8 58.9 63.8
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based o n 80_F (26.7_C) edb temperature o f air entering indoor coil.
Below 80_F (26.7_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.7_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
