Carrier 38HDR Product Data

19
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDR036 / 40QAC036
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
640/0.02 740/0.02 840/0.03
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 31.6 34.2 35.6 36.5 32.3 34.7 35.7 36.6 32.9 35.0 35.9 36.6
SHG 30.5 27.2 22.6 18.1 32.3 28.2 22.9 18.2 32.9 29.0 23.3 18.4
TC 30.9 33.5 34.9 35.7 31.6 34.0 35.0 35.8 32.2 34.3 35.1 35.9
kW 1.74 1.74 1.75 1.74 1.74 1.75 1.75 1.74 1.73 1.75 1.75 1.74
CMP 1.39 1.39 1.40 1.39 1.39 1.40 1.40 1.39 1.38 1.40 1.40 1.39
LDB 43.8 48.1 54.0 59.7 45.2 50.0 56.1 61.5 47.6 51.8 57.8 62.9
LWB 40.0 45.4 51.6 58.1 41.5 47.0 53.3 59.6 42.7 48.3 54.6 60.8
65
(18.3)
TCG 30.8 33.6 36.0 37.1 31.5 34.2 36.3 37.3 32.4 34.7 36.5 37.5
SHG 30.0 27.1 23.1 18.6 31.4 28.4 23.8 18.9 32.4 29.4 24.4 19.1
TC 30.0 32.8 35.2 36.4 30.8 33.5 35.6 36.5 31.7 34.0 35.8 36.8
kW 1.95 1.94 1.95 1.95 1.95 1.94 1.95 1.95 1.95 1.95 1.95 1.95
CMP 1.60 1.59 1.60 1.60 1.60 1.59 1.60 1.60 1.60 1.60 1.60 1.60
LDB 44.3 48.1 53.3 59.1 46.2 49.8 55.1 60.8 48.1 51.4 56.7 62.2
LWB 40.6 45.8 51.4 57.8 41.9 47.2 53.0 59.3 43.0 48.4 54.3 60.5
75
(23.9)
TCG 30.2 32.6 35.3 37.0 31.2 33.2 35.8 37.2 31.7 33.7 36.2 37.3
SHG 29.0 26.7 22.9 18.7 29.7 28.1 23.8 19.0 31.7 29.2 24.5 19.3
TC 29.4 31.8 34.5 36.3 30.5 32.4 35.0 36.4 31.0 33.0 35.4 36.6
kW 2.18 2.17 2.17 2.18 2.18 2.18 2.17 2.18 2.18 2.17 2.18 2.18
CMP 1.83 1.82 1.82 1.83 1.83 1.83 1.82 1.83 1.83 1.82 1.83 1.83
LDB 45.6 48.6 53.5 59.1 48.1 50.1 55.2 60.7 48.8 51.5 56.6 62.1
LWB 40.9 46.4 51.8 57.9 42.1 47.7 53.2 59.4 43.3 48.9 54.4 60.6
85
(29.4)
TCG 28.8 31.3 34.3 36.7 29.6 31.9 34.8 36.9 30.7 32.4 35.2 37.1
SHG 28.2 26.0 22.7 18.5 29.6 27.4 23.6 19.0 30.7 28.8 24.4 19.4
TC 28.0 30.5 33.5 35.9 28.9 31.2 34.1 36.2 30.0 31.7 34.5 36.4
kW 2.40 2.42 2.43 2.43 2.42 2.43 2.43 2.44 2.43 2.43 2.43 2.44
CMP 2.05 2.07 2.08 2.08 2.07 2.08 2.08 2.09 2.08 2.08 2.08 2.09
LDB 46.5 49.5 53.9 59.2 48.1 50.8 55.3 60.7 49.8 52.0 56.7 61.9
LWB 41.8 47.1 52.3 58.1 43.0 48.4 53.7 59.5 43.8 49.5 54.8 60.6
95
(35)
TCG 27.3 29.7 32.9 35.7 28.3 30.3 33.4 36.2 29.3 30.8 33.7 36.5
SHG 27.3 25.1 22.0 18.3 28.3 26.5 23.0 18.8 29.3 27.8 23.9 19.3
TC 26.6 28.9 32.1 35.0 27.6 29.6 32.7 35.4 28.5 30.1 33.0 35.8
kW 2.84 2.85 2.89 2.89 2.85 2.86 2.89 2.90 2.86 2.87 2.89 2.90
CMP 2.49 2.50 2.54 2.54 2.50 2.51 2.54 2.55 2.51 2.52 2.54 2.55
LDB 47.6 50.6 54.6 59.5 49.6 51.8 55.9 60.9 51.3 53.0 57.0 62.1
LWB 42.7 48.0 53.0 58.5 43.7 49.2 54.3 59.8 44.5 50.2 55.3 60.8
105
(40.6)
TCG 25.9 27.8 31.1 34.3 26.9 28.4 31.7 34.8 27.8 28.9 32.2 35.2
SHG 25.9 24.1 21.1 17.8 26.9 25.5 22.2 18.4 27.8 26.8 23.3 18.9
TC 25.1 27.0 30.3 33.6 26.2 27.7 31.0 34.1 27.0 28.2 31.4 34.5
kW 2.94 2.95 2.99 3.02 2.95 2.96 3.01 3.02 2.96 2.97 3.02 3.02
CMP 2.59 2.60 2.64 2.67 2.60 2.61 2.66 2.67 2.61 2.62 2.67 2.67
LDB 49.4 51.7 55.7 60.1 51.1 52.9 56.8 61.3 52.8 54.0 57.7 62.4
LWB 43.6 49.0 53.9 59.1 44.5 50.1 55.0 60.3 45.2 51.0 56.0 61.3
115
(46.1)
TCG 24.4 25.7 29.0 32.5 25.3 26.3 29.6 33.0 26.2 27.4 29.9 33.4
SHG 24.4 23.3 20.1 17.1 25.3 24.5 21.2 17.7 26.2 24.6 22.1 18.4
TC 23.6 25.0 28.2 31.7 24.6 25.5 28.8 32.2 25.4 26.6 29.2 32.6
kW 3.24 3.25 3.30 3.36 3.25 3.26 3.31 3.36 3.27 3.26 3.31 3.36
CMP 2.89 2.90 2.95 3.01 2.90 2.91 2.96 3.01 2.92 2.91 2.96 3.01
LDB 51.2 52.8 56.9 60.9 52.9 54.0 57.9 62.0 54.4 56.1 58.9 62.9
LWB 44.5 50.1 54.9 59.9 45.3 51.1 56.0 61.0 46.0 51.7 56.9 61.9
125
(51.7)
TCG 22.8 23.9 26.6 30.2 23.6 24.8 27.1 30.7 24.4 25.2 27.6 31.1
SHG 22.8 21.5 19.0 16.2 23.6 22.3 20.1 16.9 24.4 23.4 21.1 17.5
TC 22.0 23.1 25.8 29.5 22.9 24.0 26.4 30.0 23.7 24.4 26.8 30.3
kW 3.57 3.56 3.62 3.71 3.59 3.58 3.64 3.72 3.60 3.59 3.65 3.72
CMP 3.22 3.21 3.27 3.36 3.24 3.23 3.29 3.37 3.25 3.24 3.30 3.37
LDB 53.2 55.0 58.2 61.9 54.8 56.4 59.0 62.8 56.2 57.4 59.8 63.7
LWB 45.4 51.1 56.1 60.9 46.2 51.8 57.0 61.9 46.9 52.6 57.8 62.7
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based o n 80_F (26.7_C) edb temperature o f air entering indoor coil.
Below 80_F (26.7_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.7_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
R
