PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDR048 / 40QAC048
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
1100/0.05 1160/0.05 1200/0.06
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 44.2 45.6 47.0 48.2 44.6 45.9 47.3 48.5 44.9 46.1 47.5 48.6
SHG 44.2 36.9 30.7 25.4 44.6 37.5 31.1 25.6 44.9 38.0 31.3 25.8
TC 43.0 44.5 45.9 47.1 43.4 44.8 46.2 47.3 43.7 45.0 46.3 47.5
kW 2.42 2.42 2.42 2.42 2.42 2.42 2.42 2.42 2.42 2.42 2.42 2.42
CMP 2.07 2.07 2.07 2.07 2.07 2.07 2.07 2.07 2.07 2.07 2.07 2.07
LDB 42.5 49.1 54.8 59.7 44.7 50.7 56.2 60.9 46.0 51.7 57.1 61.6
LWB 40.1 46.4 52.7 59.0 41.2 47.5 53.7 60.0 41.9 48.1 54.3 60.5
65
(18.3)
TCG 44.8 46.4 48.1 49.6 45.4 46.8 48.4 49.9 45.8 47.0 48.6 50.0
SHG 44.8 38.7 31.9 26.1 45.4 39.6 32.4 26.3 45.8 40.1 32.7 26.5
TC 43.7 45.3 47.0 48.5 44.3 45.7 47.3 48.7 44.6 45.9 47.5 48.9
kW 2.74 2.75 2.75 2.76 2.74 2.75 2.75 2.76 2.74 2.75 2.75 2.76
CMP 2.39 2.40 2.40 2.41 2.39 2.40 2.40 2.41 2.39 2.40 2.40 2.41
LDB 41.9 47.5 53.8 59.1 44.0 49.0 55.2 60.3 45.3 50.0 56.0 61.1
LWB 39.8 46.0 52.3 58.6 40.9 47.1 53.3 59.6 41.6 47.8 54.0 60.2
75
(23.9)
TCG 44.5 46.2 48.4 50.3 45.3 46.6 48.7 50.6 46.0 46.9 49.0 50.8
SHG 44.5 39.6 32.6 26.5 45.3 40.6 33.3 26.8 46.0 41.3 33.7 27.1
TC 43.4 45.0 47.2 49.2 44.1 45.5 47.6 49.4 44.9 45.7 47.8 49.6
kW 3.08 3.10 3.12 3.12 3.09 3.10 3.12 3.12 3.09 3.11 3.12 3.12
CMP 2.73 2.75 2.77 2.77 2.74 2.75 2.77 2.77 2.74 2.76 2.77 2.77
LDB 42.2 46.7 53.1 58.7 44.2 48.2 54.4 59.9 45.1 49.0 55.2 60.6
LWB 39.9 46.1 52.2 58.4 41.0 47.2 53.2 59.4 41.5 47.9 53.8 59.9
85
(29.4)
TCG 43.2 45.4 48.0 50.1 44.3 46.0 48.4 50.5 45.0 46.2 48.6 50.7
SHG 43.2 39.8 33.0 26.6 44.3 41.2 33.8 27.0 45.0 42.1 34.3 27.3
TC 42.1 44.3 46.8 49.0 43.1 44.8 47.2 49.3 43.9 45.0 47.4 49.5
kW 3.47 3.48 3.51 3.53 3.48 3.49 3.51 3.53 3.48 3.49 3.52 3.53
CMP 3.12 3.13 3.16 3.18 3.13 3.14 3.16 3.18 3.13 3.14 3.17 3.18
LDB 43.3 46.5 52.8 58.6 44.9 47.7 54.0 59.8 45.9 48.4 54.8 60.5
LWB 40.5 46.4 52.3 58.4 41.4 47.4 53.3 59.4 41.9 48.1 54.0 60.0
95
(35)
TCG 41.3 43.3 46.4 49.7 42.4 44.1 46.8 50.0 43.2 44.5 47.1 50.2
SHG 41.3 38.9 32.7 26.6 42.4 40.7 33.5 27.1 43.2 41.7 34.2 27.4
TC 40.1 42.2 45.3 48.5 41.3 43.0 45.6 48.9 42.1 43.4 46.0 49.1
kW 3.84 3.89 3.99 4.03 3.87 3.90 3.99 4.03 3.89 3.90 4.00 4.03
CMP 3.49 3.54 3.64 3.68 3.52 3.55 3.64 3.68 3.54 3.55 3.65 3.68
LDB 45.0 47.3 52.6 58.6 46.5 48.1 53.7 59.7 47.3 48.7 54.4 60.3
LWB 41.4 47.3 52.6 58.6 42.1 48.1 53.6 59.5 42.6 48.7 54.2 60.1
105
(40.6)
TCG 39.1 40.6 45.3 48.7 40.3 41.2 45.8 49.1 41.0 41.6 46.1 49.3
SHG 39.1 37.7 32.4 26.3 40.3 39.3 33.5 27.0 41.0 40.4 34.3 27.4
TC 38.0 39.5 44.1 47.6 39.2 40.1 44.6 47.9 39.9 40.5 44.9 48.1
kW 4.24 4.27 4.38 4.44 4.26 4.29 4.39 4.44 4.29 4.30 4.40 4.45
CMP 3.89 3.92 4.03 4.09 3.91 3.94 4.04 4.09 3.94 3.95 4.05 4.10
LDB 46.9 48.3 53.3 58.9 48.2 49.2 54.2 59.8 49.0 49.7 54.7 60.3
LWB 42.4 48.3 53.3 58.9 43.0 49.2 54.2 59.8 43.4 49.7 54.7 60.3
115
(46.1)
TCG 36.6 37.3 42.1 46.8 37.8 38.0 42.6 47.4 38.6 38.6 43.0 47.7
SHG 36.6 36.2 31.0 25.6 37.8 37.8 32.2 26.3 38.6 38.6 33.0 26.8
TC 35.5 36.1 40.9 45.7 36.7 36.9 41.5 46.2 37.4 37.5 41.8 46.5
kW 4.67 4.68 4.82 4.92 4.70 4.70 4.84 4.93 4.72 4.72 4.85 4.94
CMP 4.32 4.33 4.47 4.57 4.35 4.35 4.49 4.58 4.37 4.37 4.50 4.59
LDB 49.1 49.6 54.4 59.5 50.2 50.4 55.2 60.3 50.9 51.0 55.7 60.8
LWB 43.4 49.6 54.4 59.5 44.0 50.3 55.2 60.3 44.4 50.7 55.7 60.8
125
(51.7)
TCG 34.0 34.1 38.6 43.4 35.1 35.1 39.3 44.1 35.8 35.8 39.7 44.5
SHG 34.0 34.1 29.6 24.3 35.1 35.1 30.9 25.1 35.8 35.8 31.7 25.7
TC 32.8 32.9 37.5 42.3 33.9 34.0 38.1 43.0 34.6 34.7 38.6 43.4
kW 5.13 5.13 5.25 5.42 5.16 5.16 5.27 5.44 5.18 5.18 5.29 5.45
CMP 4.78 4.78 4.90 5.07 4.81 4.81 4.92 5.09 4.83 4.83 4.94 5.10
LDB 51.4 51.4 55.6 60.5 52.4 52.5 56.3 61.2 53.1 53.2 56.7 61.6
LWB 44.6 50.9 55.6 60.5 45.1 51.3 56.3 61.2 45.4 51.6 56.7 61.6
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x ( 1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
R
