Carrier 38HDR Product Data

21
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDR060 / 40QAC060
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
1040/0.03 1220/0.04 1600/0.06
A i r E n t e r i n g E v a p o r a t o r --- E w b ( ° F )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 58.3 60.6 62.3 64.9 59.9 61.5 63.7 65.4 62.0 62.6 64.4 65.8
SHG 58.3 51.4 41.3 34.1 59.9 53.8 43.9 34.8 62.0 57.5 45.9 35.8
TC 57.1 59.4 61.1 63.7 58.7 60.3 62.4 64.2 60.8 61.4 63.1 64.6
kW 3.02 3.05 3.08 3.10 3.05 3.07 3.09 3.10 3.08 3.09 3.09 3.10
CMP 2.67 2.70 2.73 2.75 2.70 2.72 2.74 2.75 2.73 2.74 2.74 2.75
LDB 39.6 44.8 52.2 57.6 42.4 46.6 53.3 59.3 47.6 50.2 56.6 62.3
LWB 38.5 44.8 51.3 57.6 40.0 46.4 52.7 59.0 42.7 49.1 55.2 61.4
65
(18.3)
TCG 57.1 60.3 63.8 65.4 58.9 61.6 64.4 66.3 62.6 63.4 64.9 66.7
SHG 57.1 51.2 43.3 34.1 58.9 54.1 45.2 35.1 62.6 59.9 46.5 36.4
TC 55.8 59.1 62.6 64.2 57.7 60.4 63.2 65.0 61.3 62.2 63.7 65.5
kW 3.39 3.40 3.47 3.49 3.41 3.44 3.48 3.50 3.45 3.46 3.48 3.50
CMP 3.04 3.05 3.12 3.14 3.06 3.09 3.13 3.15 3.10 3.11 3.13 3.15
LDB 40.5 44.9 50.9 57.6 43.1 46.4 52.4 59.1 47.3 48.9 56.4 62.0
LWB 39.0 44.9 50.9 57.4 40.4 46.4 52.5 58.8 42.6 48.9 55.1 61.2
75
(23.9)
TCG 55.3 58.5 63.4 66.6 57.2 59.5 64.8 67.1 60.6 61.4 66.1 67.6
SHG 55.3 50.3 43.1 34.8 57.2 53.1 45.2 35.9 60.6 59.0 49.3 37.6
TC 54.0 57.2 62.1 65.4 56.0 58.2 63.5 65.9 59.4 60.2 64.9 66.4
kW 3.79 3.82 3.88 3.93 3.80 3.84 3.90 3.94 3.85 3.86 3.92 3.94
CMP 3.44 3.47 3.53 3.58 3.45 3.49 3.55 3.59 3.50 3.51 3.57 3.59
LDB 41.8 45.5 51.0 57.1 44.2 47.0 52.4 58.6 48.4 49.4 54.9 61.3
LWB 39.7 45.5 51.0 57.1 41.0 47.0 52.4 58.6 43.1 49.4 54.9 61.0
85
(29.4)
TCG 53.0 55.8 61.3 66.0 55.0 57.2 62.2 66.5 58.7 59.1 63.7 67.4
SHG 53.0 49.0 42.2 34.6 55.0 52.0 44.1 35.7 58.7 58.0 48.3 38.0
TC 51.8 54.6 60.1 64.8 53.8 56.0 61.0 65.3 57.4 57.9 62.5 66.2
kW 4.19 4.25 4.31 4.39 4.24 4.27 4.34 4.40 4.29 4.29 4.36 4.42
CMP 3.84 3.90 3.96 4.04 3.89 3.92 3.99 4.05 3.94 3.94 4.01 4.07
LDB 43.4 46.4 51.6 57.3 45.5 47.7 53.1 58.8 49.4 49.9 55.4 61.1
LWB 40.5 46.4 51.6 57.3 41.7 47.7 53.1 58.8 43.6 49.9 55.4 61.1
95
(35)
TCG 50.6 52.8 55.3 63.4 52.6 54.0 56.5 64.4 56.0 56.1 58.3 66.4
SHG 50.6 47.6 38.9 33.6 52.6 50.5 40.9 34.9 56.0 56.1 45.1 37.7
TC 49.4 51.5 54.1 62.2 51.4 52.7 55.3 63.1 54.8 54.9 57.0 65.2
kW 4.62 4.67 4.96 5.05 4.67 4.71 4.97 5.07 4.77 4.77 5.00 5.09
CMP 4.27 4.32 4.61 4.70 4.32 4.36 4.62 4.72 4.42 4.42 4.65 4.74
LDB 45.1 47.4 52.6 58.0 47.1 48.7 53.8 59.3 50.8 50.9 55.9 61.3
LWB 41.4 47.4 52.6 58.0 42.5 48.6 53.8 59.3 44.3 50.6 55.9 61.3
105
(40.6)
TCG 47.6 49.2 54.5 60.3 49.8 49.8 55.6 61.4 53.1 53.2 57.4 63.0
SHG 47.6 45.9 39.2 32.4 49.8 49.8 41.4 33.7 53.1 53.2 45.8 36.4
TC 46.4 47.9 53.3 59.1 48.5 48.6 54.3 60.1 51.9 52.0 56.2 61.7
kW 5.07 5.11 5.27 5.39 5.14 5.14 5.31 5.41 5.23 5.24 5.35 5.45
CMP 4.72 4.76 4.92 5.04 4.79 4.79 4.96 5.06 4.88 4.89 5.00 5.10
LDB 47.2 48.6 53.6 58.8 48.9 49.1 54.8 60.0 52.4 52.5 56.7 61.9
LWB 42.5 48.6 53.6 58.8 43.4 49.8 54.8 60.0 45.0 51.3 56.7 61.9
115
(46.1)
TCG 44.6 44.7 50.4 56.4 46.7 46.6 51.5 57.5 49.9 49.9 53.4 59.2
SHG 44.6 44.7 37.6 30.9 46.7 46.6 39.7 32.3 49.9 49.9 44.2 35.1
TC 43.4 43.5 49.2 55.2 45.5 45.4 50.3 56.3 48.6 48.7 52.1 58.0
kW 5.59 5.60 5.73 5.93 5.66 5.65 5.76 5.97 5.74 5.74 5.84 5.99
CMP 5.24 5.25 5.38 5.58 5.31 5.30 5.41 5.62 5.39 5.39 5.49 5.64
LDB 49.3 49.4 54.8 59.8 50.9 51.1 55.8 60.8 54.1 54.2 57.5 62.6
LWB 43.5 49.9 54.8 59.8 44.3 50.7 55.8 60.8 45.9 52.0 57.5 62.6
125
(51.7)
TCG 41.4 41.5 45.8 52.2 43.2 43.1 46.8 53.2 46.2 46.2 48.7 54.6
SHG 41.4 41.5 35.7 29.4 43.2 43.1 37.8 30.7 46.2 46.2 42.3 33.4
TC 40.2 40.2 44.6 51.0 42.0 41.9 45.6 51.9 44.9 45.0 47.4 53.4
kW 6.15 6.15 6.25 6.43 6.21 6.19 6.28 6.47 6.28 6.28 6.34 6.55
CMP 5.80 5.80 5.90 6.08 5.86 5.84 5.93 6.12 5.93 5.93 5.99 6.20
LDB 51.5 51.7 56.0 60.8 53.1 53.3 56.9 61.8 56.1 56.2 58.4 63.4
LWB 44.7 51.0 56.0 60.8 45.4 51.7 56.9 61.8 46.8 52.9 58.4 63.4
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x ( 1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
