Carrier 38HDR Product Data

23
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38QRR024 / 40QAQ024
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
400/0.03 500/0.03 600/0.04
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 20.5 22.4 24.1 25.3 21.5 23.4 24.7 25.3 21.7 23.9 25.1 26.0
SHG 18.7 17.0 15.0 12.7 20.6 18.5 15.8 13.1 21.0 19.5 16.3 13.4
TC 20.2 22.1 23.8 25.0 21.2 23.1 24.4 25.0 21.4 23.6 24.8 25.6
kW 1.18 1.18 1.19 1.20 1.18 1.19 1.19 1.19 1.18 1.19 1.20 1.20
CMP 0.99 1.00 1.00 1.01 0.99 1.00 1.01 1.00 0.99 1.00 1.01 1.01
LDB 38.0 42.2 47.0 52.8 41.4 45.6 51.1 56.6 42.1 48.3 54.0 59.1
LWB 35.3 40.5 46.3 52.8 38.5 43.8 49.9 56.5 39.2 46.1 52.1 58.4
65
(18.3)
TCG 19.7 21.7 23.7 25.3 20.7 22.8 24.6 25.8 21.0 23.4 25.1 26.1
SHG 18.1 16.5 14.8 12.7 19.9 18.1 15.8 13.1 20.4 19.4 16.5 13.4
TC 19.4 21.4 23.4 25.0 20.4 22.4 24.3 25.5 20.6 23.1 24.7 25.8
kW 1.32 1.34 1.35 1.35 1.33 1.34 1.35 1.36 1.33 1.34 1.35 1.36
CMP 1.13 1.15 1.16 1.17 1.15 1.16 1.16 1.17 1.15 1.16 1.17 1.18
LDB 39.2 43.3 47.6 52.8 42.6 46.3 51.1 56.5 43.3 48.5 53.7 59.0
LWB 36.4 41.3 46.7 52.8 39.3 44.4 50.0 56.2 39.9 46.5 52.2 58.3
75
(23.9)
TCG 18.9 20.8 23.0 24.9 19.8 21.9 24.0 25.7 19.9 22.6 24.6 26.1
SHG 17.7 16.0 14.3 12.5 19.3 17.5 15.5 13.1 19.9 18.9 16.4 13.4
TC 18.5 20.5 22.7 24.6 19.5 21.5 23.7 25.4 19.6 22.2 24.3 25.7
kW 1.47 1.50 1.52 1.53 1.49 1.51 1.52 1.53 1.49 1.52 1.53 1.54
CMP 1.29 1.32 1.33 1.34 1.30 1.33 1.34 1.35 1.30 1.33 1.34 1.35
LDB 40.3 44.5 48.6 53.2 43.7 47.5 51.6 56.6 44.0 49.3 53.8 59.0
LWB 37.4 42.4 47.5 53.1 40.2 45.2 50.5 56.3 40.9 47.2 52.5 58.4
85
(29.4)
TCG 18.0 19.9 22.0 24.2 18.8 20.8 23.1 25.1 19.1 21.5 23.7 25.6
SHG 17.1 15.5 13.8 12.1 18.8 17.0 15.0 12.8 19.1 18.2 16.0 13.3
TC 17.6 19.6 21.7 23.9 18.5 20.5 22.7 24.8 18.8 21.1 23.4 25.3
kW 1.64 1.68 1.71 1.72 1.66 1.69 1.71 1.73 1.66 1.70 1.72 1.73
CMP 1.46 1.49 1.52 1.53 1.47 1.51 1.53 1.54 1.48 1.52 1.53 1.54
LDB 41.5 45.7 49.9 54.0 44.7 48.5 52.5 57.0 45.6 50.4 54.4 59.2
LWB 38.5 43.5 48.5 53.8 41.2 46.2 51.3 56.7 41.7 48.0 53.1 58.6
95
(35)
TCG 17.0 18.8 20.9 23.2 18.0 19.7 21.9 24.1 18.3 20.3 23.3 24.7
SHG 16.6 14.9 13.2 11.6 18.0 16.4 14.4 12.4 18.3 17.6 16.0 13.0
TC 16.7 18.5 20.6 22.9 17.7 19.4 21.6 23.8 17.9 20.0 23.0 24.4
kW 1.92 1.96 2.00 2.03 1.94 1.98 2.02 2.03 1.95 1.99 2.02 2.04
CMP 1.74 1.78 1.82 1.84 1.76 1.79 1.83 1.85 1.76 1.81 1.84 1.85
LDB 42.8 46.8 51.1 55.2 46.3 49.6 53.7 57.8 47.1 51.4 55.3 59.7
LWB 39.7 44.6 49.6 54.7 42.0 47.2 52.2 57.4 42.5 48.9 53.9 59.2
105
(40.6)
TCG 15.9 17.7 19.7 22.0 17.1 18.5 20.6 22.9 17.4 19.0 21.2 23.5
SHG 15.9 14.4 12.7 11.0 17.1 15.8 13.8 11.9 17.4 17.0 14.8 12.5
TC 15.6 17.4 19.4 21.7 16.8 18.2 20.3 22.6 17.0 18.7 20.8 23.2
kW 2.01 2.06 2.11 2.15 2.04 2.08 2.13 2.16 2.05 2.09 2.14 2.16
CMP 1.83 1.87 1.92 1.96 1.86 1.89 1.94 1.97 1.86 1.91 1.96 1.98
LDB 44.3 48.1 52.4 56.4 48.0 50.7 54.8 58.8 48.7 52.5 56.4 60.5
LWB 41.0 45.8 50.8 55.8 42.9 48.2 53.2 58.3 43.3 49.8 54.8 59.9
115
(46.1)
TCG 15.0 16.5 18.4 20.6 16.1 17.2 19.2 21.5 16.4 17.7 19.7 22.1
SHG 15.0 13.8 12.1 10.4 16.1 15.2 13.2 11.3 16.4 16.3 14.1 11.9
TC 14.6 16.1 18.1 20.2 15.8 16.9 18.9 21.2 16.0 17.4 19.4 21.7
kW 2.23 2.27 2.32 2.38 2.26 2.29 2.35 2.40 2.26 2.30 2.36 2.40
CMP 2.04 2.08 2.14 2.20 2.07 2.10 2.16 2.21 2.08 2.12 2.18 2.21
LDB 46.4 49.5 53.7 57.9 49.8 51.9 56.0 59.9 50.6 53.5 57.4 61.4
LWB 42.1 47.2 52.1 57.1 43.8 49.3 54.3 59.3 44.2 50.8 55.8 60.8
125
(51.7)
TCG 14.0 15.1 17.0 19.1 15.0 15.7 17.7 19.8 15.3 16.2 18.1 20.4
SHG 14.0 13.1 11.4 9.8 15.0 14.5 12.5 10.6 15.3 15.6 13.4 11.2
TC 13.6 14.7 16.7 18.7 14.7 15.4 17.3 19.5 14.9 15.9 17.8 20.0
kW 2.45 2.49 2.55 2.62 2.49 2.51 2.58 2.65 2.49 2.53 2.59 2.65
CMP 2.27 2.30 2.36 2.44 2.30 2.32 2.39 2.46 2.31 2.34 2.41 2.47
LDB 48.8 50.9 55.1 59.2 51.9 53.2 57.2 61.2 52.6 54.8 58.6 62.5
LWB 43.3 48.6 53.4 58.4 44.8 50.6 55.4 60.4 45.2 51.8 56.8 61.7
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based o n 80_F (26.7_C) edb temperature o f air entering indoor coil.
Below 80_F (26.7_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.7_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
