Carrier 38HDR Product Data

26
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38QRR048 / 40QAQ048
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
1100/0.05 1160/0.05 1200/0.06
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 43.5 45.4 47.0 48.4 44.2 46.3 47.8 49.2 45.0 46.8 48.3 49.7
SHG 40.9 35.0 29.8 24.8 43.9 36.7 30.8 25.8 45.0 38.0 31.6 26.2
TC 42.4 44.3 45.8 47.3 43.1 45.1 46.6 48.0 43.9 45.7 47.2 48.5
kW 2.44 2.44 2.44 2.44 2.43 2.44 2.44 2.44 2.43 2.44 2.44 2.43
CMP 2.09 2.09 2.09 2.09 2.08 2.09 2.09 2.09 2.08 2.09 2.09 2.08
LDB 35.6 42.5 48.7 54.6 39.8 46.9 52.7 57.7 43.4 49.6 55.2 59.9
LWB 34.7 41.1 47.8 54.6 38.5 44.6 51.1 57.5 40.6 46.7 53.0 59.3
65
(18.3)
TCG 42.4 45.1 47.0 48.8 44.0 46.1 48.0 49.8 45.1 46.8 48.6 50.3
SHG 40.4 35.1 30.0 25.0 44.0 37.2 31.3 26.1 45.1 38.7 32.2 26.6
TC 41.3 44.0 45.9 47.7 42.9 45.0 46.8 48.6 43.9 45.7 47.5 49.2
kW 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.75 2.76 2.76 2.76
CMP 2.41 2.41 2.41 2.41 2.41 2.41 2.41 2.41 2.40 2.41 2.41 2.41
LDB 36.2 42.4 48.5 54.4 39.7 46.4 52.3 57.4 43.4 49.0 54.7 59.6
LWB 35.4 41.3 47.8 54.4 38.6 44.7 51.0 57.3 40.6 46.7 52.9 59.1
75
(23.9)
TCG 40.7 44.6 46.6 48.6 43.2 45.7 47.6 49.4 44.6 46.4 48.2 49.9
SHG 39.2 35.2 30.1 24.9 43.2 37.5 31.3 26.1 44.6 39.2 32.3 26.5
TC 39.5 43.5 45.5 47.5 42.1 44.6 46.5 48.2 43.4 45.2 47.1 48.8
kW 3.09 3.11 3.11 3.11 3.11 3.11 3.11 3.11 3.11 3.11 3.11 3.11
CMP 2.74 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76
LDB 37.5 42.4 48.3 54.5 40.4 46.2 52.2 57.5 43.8 48.5 54.6 59.7
LWB 36.5 41.6 48.0 54.5 39.0 44.9 51.1 57.5 40.8 46.9 53.0 59.2
85
(29.4)
TCG 38.7 42.8 46.3 48.1 41.3 44.9 47.3 49.0 43.6 45.7 47.7 49.5
SHG 38.1 34.3 29.7 24.7 41.3 37.6 31.4 25.9 43.6 39.5 32.7 26.3
TC 37.6 41.7 45.2 47.0 40.1 43.7 46.1 47.8 42.4 44.5 46.5 48.3
kW 3.43 3.48 3.50 3.50 3.48 3.49 3.50 3.51 3.50 3.49 3.50 3.50
CMP 3.08 3.13 3.15 3.15 3.13 3.14 3.15 3.16 3.15 3.14 3.15 3.15
LDB 38.7 43.2 48.8 54.7 42.3 46.0 52.1 57.6 44.7 48.3 54.3 59.8
LWB 37.7 42.6 48.1 54.7 40.0 45.3 51.3 57.6 41.2 47.1 53.2 59.3
95
(35)
TCG 36.8 40.6 45.1 47.5 39.4 42.4 46.5 48.3 41.4 43.9 46.1 48.9
SHG 36.8 33.2 29.4 24.2 39.4 36.3 31.1 25.6 41.4 39.0 31.8 26.2
TC 35.6 39.5 44.0 46.4 38.2 41.3 45.3 47.1 40.3 42.8 45.0 47.7
kW 3.80 3.86 3.89 3.92 3.86 3.89 3.89 3.92 3.89 3.90 3.90 3.93
CMP 3.45 3.51 3.54 3.57 3.51 3.54 3.54 3.57 3.54 3.55 3.55 3.58
LDB 40.2 44.5 49.1 55.3 44.1 47.2 52.4 57.8 46.4 48.7 54.5 59.9
LWB 38.9 43.8 48.7 55.0 40.9 46.3 51.6 57.8 42.1 47.8 53.4 59.5
105
(40.6)
TCG 34.7 38.3 42.7 46.4 37.4 40.0 44.6 47.3 39.3 41.1 45.6 47.8
SHG 34.7 32.0 28.2 23.6 37.4 35.1 30.7 24.9 39.3 37.5 32.2 25.8
TC 33.6 37.1 41.6 45.2 36.2 38.8 43.5 46.1 38.1 39.9 44.5 46.6
kW 4.23 4.26 4.35 4.37 4.28 4.30 4.37 4.38 4.31 4.32 4.37 4.38
CMP 3.88 3.91 4.00 4.02 3.93 3.95 4.02 4.03 3.96 3.97 4.02 4.03
LDB 42.4 45.8 50.4 55.8 45.9 48.3 52.8 58.6 48.2 49.9 54.6 60.2
LWB 40.1 45.1 49.9 55.5 41.9 47.4 52.3 58.2 43.0 48.9 53.9 59.8
115
(46.1)
TCG 33.0 35.6 40.0 44.6 35.3 37.3 41.8 45.5 37.0 38.3 42.9 46.0
SHG 33.0 30.8 27.0 23.1 35.3 33.8 29.3 24.1 37.0 36.1 31.2 25.0
TC 31.8 34.5 38.8 43.4 34.2 36.1 40.7 44.3 35.8 37.2 41.7 44.9
kW 4.65 4.69 4.78 4.85 4.72 4.73 4.83 4.85 4.76 4.75 4.85 4.86
CMP 4.30 4.34 4.43 4.50 4.37 4.38 4.48 4.50 4.41 4.40 4.50 4.51
LDB 44.4 47.2 51.7 56.4 47.9 49.5 54.0 59.2 50.1 51.0 55.4 60.9
LWB 41.1 46.5 51.2 56.2 42.8 48.6 53.4 58.8 44.0 49.9 54.8 60.4
125
(51.7)
TCG 30.8 32.6 37.0 41.7 33.1 34.2 38.6 43.0 34.6 35.3 39.7 43.4
SHG 30.8 29.3 25.7 21.9 33.1 32.4 28.0 23.2 34.6 34.6 29.8 24.1
TC 29.6 31.4 35.9 40.5 31.9 33.1 37.5 41.8 33.4 34.1 38.5 42.3
kW 5.13 5.16 5.25 5.36 5.19 5.19 5.30 5.36 5.24 5.22 5.33 5.37
CMP 4.78 4.81 4.90 5.01 4.84 4.84 4.95 5.01 4.89 4.87 4.98 5.02
LDB 46.9 48.8 53.1 57.7 50.0 50.8 55.3 60.1 52.1 52.3 56.6 61.6
LWB 42.3 48.0 52.6 57.5 43.9 49.8 54.6 59.7 44.9 51.0 55.8 61.1
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based o n 80_F (26.7_C) edb temperature o f air entering indoor coil.
Below 80_F (26.7_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.7_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
