Carrier 38HDR Product Data

27
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38QRR060 / 40QAQ060
Te m p ° F ( ° C ) A i r
Entering
Condenser (Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
1040/0.03 1220/0.04 1600/0.06
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 51.5 56.2 61.5 67.3 54.5 59.2 64.6 70.6 60.6 63.8 69.4 75.5
SHG 49.4 44.6 39.6 33.8 54.0 48.6 42.6 36.0 60.6 56.3 48.5 40.2
TC 50.3 55.0 60.3 66.0 53.3 58.0 63.4 69.3 59.4 62.5 68.2 74.3
kW 3.01 3.05 3.10 3.15 3.03 3.08 3.13 3.18 3.09 3.12 3.17 3.23
CMP 2.66 2.70 2.75 2.80 2.68 2.73 2.78 2.83 2.74 2.77 2.82 2.88
LDB 37.5 42.2 46.9 52.4 40.4 44.7 49.6 54.9 46.0 48.7 53.5 58.5
LWB 36.4 41.6 46.9 52.4 38.8 44.1 49.4 54.9 41.9 47.7 53.1 58.5
65
(18.3)
TCG 49.7 54.2 59.2 64.8 52.5 56.9 62.1 67.8 58.5 61.2 66.5 72.4
SHG 48.1 43.5 38.5 32.7 52.5 47.3 41.4 34.9 58.5 54.9 47.1 39.0
TC 48.5 53.0 57.9 63.6 51.3 55.7 60.9 66.6 57.3 59.9 65.3 71.2
kW 3.36 3.40 3.45 3.50 3.38 3.43 3.47 3.53 3.44 3.47 3.52 3.57
CMP 3.01 3.05 3.10 3.15 3.03 3.08 3.12 3.18 3.09 3.12 3.17 3.22
LDB 38.7 43.1 47.8 53.3 41.4 45.7 50.4 55.7 47.2 49.5 54.3 59.1
LWB 37.3 42.5 47.9 53.3 39.5 44.9 50.2 55.7 42.5 48.4 53.7 59.1
75
(23.9)
TCG 47.8 52.0 56.8 62.1 50.7 54.5 59.5 65.0 56.4 58.5 63.6 69.1
SHG 46.8 42.2 37.2 31.6 50.7 46.1 40.1 33.7 56.4 53.4 45.7 37.7
TC 46.6 50.8 55.6 60.9 49.4 53.3 58.3 63.7 55.1 57.2 62.4 67.9
kW 3.74 3.78 3.83 3.89 3.77 3.81 3.86 3.91 3.83 3.85 3.90 3.96
CMP 3.39 3.43 3.48 3.54 3.42 3.46 3.51 3.56 3.48 3.50 3.55 3.61
LDB 39.9 44.2 48.9 54.2 42.8 46.6 51.4 56.5 48.4 50.3 55.0 59.9
LWB 38.2 43.5 48.8 54.2 40.3 45.8 51.1 56.5 43.1 49.1 54.4 59.8
85
(29.4)
TCG 46.0 49.7 54.3 59.4 48.8 52.1 56.8 61.9 54.1 55.7 60.5 65.7
SHG 45.7 41.0 36.0 30.5 48.8 44.7 38.8 32.5 54.1 51.8 44.2 36.3
TC 44.8 48.5 53.1 58.1 47.5 50.8 55.6 60.7 52.9 54.4 59.2 64.5
kW 4.17 4.21 4.26 4.31 4.20 4.24 4.28 4.34 4.26 4.27 4.32 4.37
CMP 3.82 3.86 3.91 3.96 3.85 3.89 3.93 3.99 3.91 3.92 3.97 4.02
LDB 40.8 45.3 50.0 55.2 44.3 47.6 52.3 57.4 49.7 51.2 55.9 60.6
LWB 39.1 44.5 49.8 55.2 41.0 46.6 51.9 57.4 43.8 49.8 55.1 60.5
95
(35)
TCG 43.9 47.4 51.7 56.5 46.8 49.4 53.9 58.7 51.7 52.8 57.2 62.1
SHG 43.9 40.0 34.7 29.3 46.8 43.3 37.4 31.3 51.7 50.1 42.6 34.8
TC 42.7 46.2 50.5 55.2 45.5 48.2 52.7 57.5 50.4 51.5 56.0 60.9
kW 4.77 4.81 4.85 4.90 4.80 4.83 4.88 4.93 4.85 4.86 4.91 4.96
CMP 4.42 4.46 4.50 4.55 4.45 4.48 4.53 4.58 4.50 4.51 4.56 4.61
LDB 42.4 46.2 51.1 56.2 45.8 48.6 53.4 58.2 51.1 52.2 56.7 61.4
LWB 40.0 45.4 50.8 56.2 41.8 47.5 52.8 58.2 44.4 50.5 55.8 61.2
105
(40.6)
TCG 42.0 44.9 48.9 53.3 44.6 46.6 50.9 55.3 49.1 49.7 53.8 58.3
SHG 42.0 38.6 33.3 28.1 44.6 41.7 36.0 30.0 49.1 48.2 41.0 33.3
TC 40.8 43.6 47.6 52.1 43.3 45.4 49.6 54.1 47.9 48.5 52.5 57.1
kW 5.16 5.19 5.22 5.27 5.18 5.20 5.24 5.29 5.22 5.23 5.27 5.31
CMP 4.81 4.84 4.87 4.92 4.83 4.85 4.89 4.94 4.87 4.88 4.92 4.96
LDB 44.1 47.3 52.3 57.2 47.4 49.8 54.4 59.2 52.6 53.3 57.6 62.3
LWB 40.9 46.5 51.8 57.2 42.6 48.5 53.8 59.2 45.2 51.3 56.6 62.0
115
(46.1)
TCG 39.8 42.0 45.8 49.9 42.2 43.6 47.5 51.6 46.3 46.4 50.0 54.0
SHG 39.8 37.0 31.8 26.7 42.2 40.0 34.3 28.5 46.3 46.4 39.2 31.5
TC 38.5 40.8 44.6 48.6 40.9 42.4 46.3 50.4 45.1 45.2 48.8 52.8
kW 5.70 5.72 5.75 5.80 5.72 5.74 5.77 5.81 5.76 5.76 5.79 5.83
CMP 5.35 5.37 5.40 5.45 5.37 5.39 5.42 5.46 5.41 5.41 5.44 5.48
LDB 46.0 48.7 53.6 58.4 49.2 51.1 55.6 60.3 54.2 54.2 58.6 63.2
LWB 41.9 47.7 53.0 58.4 43.5 49.5 54.8 60.2 45.9 52.1 57.4 62.8
125
(51.7)
TCG 37.2 38.8 42.3 45.9 39.4 40.3 43.7 47.2 43.0 43.1 45.6 49.0
SHG 37.2 35.1 30.1 25.2 39.4 38.1 32.5 26.7 43.0 42.8 37.1 29.5
TC 36.0 37.6 41.0 44.6 38.2 39.1 42.5 46.0 41.8 41.9 44.4 47.8
kW 6.27 6.29 6.31 6.35 6.28 6.29 6.32 6.36 6.32 6.31 6.34 6.37
CMP 5.92 5.94 5.96 6.00 5.93 5.94 5.97 6.01 5.97 5.96 5.99 6.02
LDB 48.3 50.4 55.1 59.7 51.3 52.5 56.9 61.5 56.1 56.3 59.8 64.4
LWB 43.1 48.9 54.2 59.7 44.5 50.6 55.9 61.3 46.8 52.9 58.4 63.8
Rating Condition.
Not recommended for long--- term operation
BF --- B y p a s s Fa c t o r
CMP --- C o m p r e s so r
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
kW --- To t a l Po w e r
LDB --- L e a v i n g D r y Bu l b
LWB --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btuh)
TC --- Total Net Cooling Capacity (1000 Btuh)
TCG --- Gross C ooling Ca pacity (1000 Btuh)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based o n 80_F (26.7_C) edb temperature o f air entering indoor coil.
Below 80_F (26.7_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.7_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
40QAC/38HDR -- 40QAQ/38QR
