29
PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEG. HEATING RATINGS
40QAQ024 / 38QRR024
Air
Te m p e r a t ur e
Entering
Indoor Unit
°F(°C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil ° F C)
17 ( --- 8.3) 27 ( --- 2.8) 37 (2.8) 47 (8.3) 57 (13.9)
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
55
(12.8)
400
Cap 14.39 13.12 17.34 15.40 20.21 18.39 24.04 24.04 27.43 27.43
kW 1.55 1.60 1.74 1.94 2.34
480
Cap 14.60 13.31 17.60 15.63 20.38 18.54 24.53 24.53 28.21 28.21
kW 1.48 1.51 1.68 1.81 2.21
550
Cap 14.69 13.39 17.70 15.72 20.82 18.94 24.78 24.78 28.65 28.65
kW 1.43 1.48 1.57 1.75 2.06
60
(15.6)
400
Cap 14.19 12.94 17.12 15.20 19.98 18.18 23.69 23.69 27.12 27.12
kW 1.63 1.68 1.82 2.03 2.42
480
Cap 14.37 13.10 17.40 15.46 20.29 18.47 24.19 24.19 27.66 27.66
kW 1.55 1.58 1.72 1.90 2.34
550
Cap 14.49 13.21 17.58 15.62 20.66 18.80 24.49 24.49 28.49 28.49
kW 1.50 1.52 1.61 1.82 2.42
65
(18.3)
400
Cap 14.00 12.77 16.89 15.00 19.74 17.96 23.36 23.36 26.80 26.80
kW 1.70 1.76 1.90 2.11 2.50
480
Cap 14.18 12.93 17.18 15.26 20.13 18.32 23.85 23.85 27.26 27.26
kW 1.63 1.66 1.77 1.99 2.42
550
Cap 14.29 13.03 17.34 15.40 20.23 18.41 24.14 24.14 27.88 27.88
kW 1.58 1.60 1.74 1.90 2.30
70
(21.1)
400
Cap 13.80 12.58 16.72 14.85 19.44 17.69 23.00 23.00 26.42 26.42
kW 1.78 1.83 1.98 2.23 2.60
480
Cap 13.99 12.75 16.95 15.05 19.81 18.03 23.43 23.43 26.98 26.98
kW 1.71 1.74 1.88 2.11 2.50
550
Cap 14.10 12.86 17.11 15.20 19.98 18.19 23.80 23.80 27.38 27.38
kW 1.66 1.68 1.82 2.00 2.35
75
(23.9)
400
Cap 13.57 8.66 16.51 14.66 19.22 8.66 22.53 22.53 25.71 25.71
kW 1.86 1.91 2.07 2.36 2.79
480
Cap 13.77 8.89 16.73 14.86 19.55 8.89 23.16 23.16 26.54 26.54
kW 1.79 1.82 1.94 2.20 2.56
550
Cap 13.90 12.67 16.87 14.98 19.71 17.94 23.37 23.37 26.95 26.95
kW 1.75 1.77 1.91 2.11 2.50
80
(26.7)
400
Cap 13.32 12.15 16.00 14.21 18.80 17.11 22.11 22.11 25.30 25.30
kW 1.94 1.99 2.22 2.43 2.89
480
Cap 13.54 12.34 16.52 14.67 19.12 17.40 22.97 22.97 26.05 26.05
kW 1.87 1.91 2.10 2.25 2.76
550
Cap 13.67 8.66 16.65 14.79 19.38 17.64 23.27 23.27 26.27 26.27
kW 1.83 1.86 2.02 2.15 2.65
Rating Condition.
Not recommended for long--- term operation
Cap --- Heating C a pacity (1000 Btuh), includes indoor fan motor heat.
kW --- Total power input. Includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input.
NOTE: Integ. Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
40QAC/38HDR -- 40QAQ/38QR
R
