PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEG. HEATING RATINGS
40QAQ036 / 38QRR030
Air
Te m p e r a t ur e
Entering
Indoor Unit
°F(°C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil ° F (° C)
17 ( --- 8.3) 27 ( --- 2.8) 37 (2.8) 47 (8.3) 57 (13.9)
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
Instant.
Rating
Integ.
Rating
55
(12.8)
630
Cap 16.44 14.99 20.75 18.43 23.89 21.74 28.90 28.90 32.23 32.23
kW 1.92 2.01 2.10 2.20 2.29
750
Cap 16.60 15.13 20.84 18.51 24.57 22.36 29.08 29.08 32.39 32.39
kW 1.87 1.91 1.94 1.98 2.08
870
Cap 16.86 15.37 21.19 18.82 24.94 22.69 29.38 29.38 32.65 32.65
kW 1.83 1.85 1.86 1.88 1.96
60
(15.6)
400
Cap 16.12 14.70 20.61 18.31 23.66 21.53 28.67 28.67 32.00 32.00
kW 1.99 2.09 2.19 2.29 2.40
480
Cap 16.37 14.92 20.89 18.55 23.93 21.77 29.07 29.07 32.25 32.25
kW 1.94 1.99 2.05 2.10 2.18
550
Cap 16.55 15.09 21.04 18.68 24.42 22.22 28.68 28.68 32.43 32.43
kW 1.90 1.93 1.95 1.98 2.08
65
(18.3)
400
Cap 15.53 14.16 20.30 18.03 22.84 20.79 27.99 27.99 30.79 30.79
kW 2.10 2.21 2.32 2.44 2.62
480
Cap 16.06 14.64 20.62 18.31 23.74 21.61 28.79 28.79 31.67 31.67
kW 2.01 2.08 2.15 2.22 2.31
550
Cap 16.21 14.78 20.80 18.47 24.13 21.96 29.13 29.13 32.05 32.05
kW 1.97 2.01 2.06 2.10 2.22
70
(21.1)
400
Cap 15.08 13.75 19.93 17.70 22.78 20.73 27.44 27.44 30.18 30.18
kW 2.18 2.29 2.41 2.52 2.76
480
Cap 15.59 14.22 20.28 18.01 23.25 21.16 28.32 28.32 31.15 31.15
kW 2.10 2.21 2.31 2.41 2.45
550
Cap 15.71 14.33 20.50 18.21 23.50 21.38 28.84 28.84 31.72 31.72
kW 2.05 2.11 2.18 2.24 2.31
75
(23.9)
400
Cap 14.79 8.66 19.57 17.38 22.47 8.66 26.91 26.91 29.60 29.60
kW 2.23 2.35 2.46 2.57 2.80
480
Cap 15.10 8.89 19.89 17.67 22.56 8.89 27.54 27.54 30.29 30.29
kW 2.19 2.28 2.38 2.47 2.59
550
Cap 15.41 14.05 20.13 17.87 23.13 21.05 28.33 28.33 31.17 31.17
kW 2.13 2.21 2.28 2.35 2.45
80
(26.7)
400
Cap 14.26 13.01 19.21 17.06 22.24 20.24 26.69 26.69 29.35 29.35
kW 2.31 2.40 2.49 2.58 3.18
480
Cap 14.70 13.40 19.52 17.34 22.56 20.53 27.10 27.10 29.81 29.81
kW 2.25 2.35 2.45 2.55 2.77
550
Cap 14.80 8.66 19.73 17.53 22.64 20.60 27.79 27.79 30.56 30.56
kW 2.24 2.31 2.38 2.45 2.59
Rating Condition.
Not recommended for long--- term operation
Cap --- Heating C a pacity (1000 Btuh), includes indoor fan motor heat.
kW --- Total power input. Includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input.
NOTE: Integ. Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
40QAC/38HDR -- 40QAQ/38QR
