Table I: Weights and geometric dimensions
GB-6
40DMC ØAM ØAN ØAP kg
018 1/4” 1/2” 21 32
024 1/4” 1/2” 21 35
028 1/4” 5/8” 21 35
036 - 052 3/8” 3/4” 21 48
060 3/8” 3/4” 21 53
NB: All measurements are expressed in mm.
Technical data
Table II: Nominal data
Maximum electrical consumption values [W]
Cooling and heat pump heating mode only
Unit Cooling / Heating
40DMC018 140
40DMC024 160
40DMC028 250
40DMC036 365
40DMC052 430
40DMC060 580
Notes: For sizing the system’s electrical supply cable and slow-blow fuses, consult the
outdoor unit installation manual. Consumption values are measured with free inlet and
outlet at High speed and with a voltage of 264 V ~ 50 Hz.
40DMC A B C D
018 - 024 - 028 925 971 865 779
036 - 052 - 060 1325 1371 1265 1179
