Carrier 40RM007-034 - Electrical Data, Standard Motors

22
Table 4 — Electrical Data, Standard Motors
See Legend and Notes on page 23.
UNIT V*-PH-Hz
VOLTAGE
LIMITS
FAN MOTOR POWER SUPPLY
Hp (kW) FLA
Minimum
Circuit Amps
MOCP
40RM
007
208/230-1-60 187-253 1.3 (0.97) 7.6 9.5 15
208/230-3-60 187-253 2.4 (1.79) 5.8 7.3 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 1.0 (0.75) 1.4 1.7 15
230-3-50 207-253 2.4 (1.79) 5.2 6.5 15
400-3-50 360-440 2.4 (1.79) 2.6 3.3 15
40RM
40RMQ
40RMS
008
208/230-1-60 187-253 2.4 (1.79) 11.0 13.8 20
208/230-3-60 187-253 2.4 (1.79) 5.8 7.3 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 2.0 (1.49) 2.4 8.0 15
230-3-50 207-253 2.4 (1.79) 5.2 6.5 15
400-3-50 360-440 2.4 (1.79) 2.6 3.3 15
40RMS
010
208/230-1-60 187-253 2.4 (1.79) 11.0 13.8 20
208/230-3-60 187-253 2.4 (1.79) 5.2 6.5 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 2.0 (1.49) 2.3 2.9 15
230-3-50 207-253 2.4 (1.79) 5.2 6.5 15
400-3-50 360-440 2.4 (1.79) 2.6 3.3 15
40RM
40RMQ
40RMS
012
208/230-3-60 187-253 2.4 (1.79) 5.8 7.5 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 2.0 (1.49) 2.4 3.0 15
230-3-50 207-253 2.9 (2.16) 7.5 9.4 15
400-3-50 360-440 2.9 (2.16) 3.4 4.3 15
40RM
40RMS
014
208/230-3-60 187-253 2.9 (2.16) 7.5 9.4 15
460-3-60 414-506 2.9 (2.16) 3.4 4.3 15
575-3-60 518-632 3.0 (2.24) 3.8 4.8 15
230-3-50 207-253 2.9 (2.16) 7.5 9.4 15
400-3-50 360-440 2.9 (2.16) 3.4 4.3 15
40RM
40RMQ
40RMS
016
208/230-3-60 187-253 3.7 (2.76) 10.6 13.3 20
460-3-60 414-506 3.7 (2.76) 4.8 6.0 15
575-3-60 518-632 3.0 (2.24) 3.8 4.8 15
230-3-50 207-253 2.9 (2.16) 7.5 9.4 15
400-3-50 360-440 2.9 (2.16) 3.4 4.3 15
40RM
40RMQ
40RMS
024
208/230-3-60 187-253 5.0 (3.73) 14.6/12.8 18.3/16.0 30/25
460-3-60 414-506 5.0 (3.73) 6.4 8.0 15
575-3-60 518-632 5.0 (3.73) 5.1 6.4 15
230-3-50 207-253 5.0 (3.73) 15.2 19.0 30
400-3-50 360-440 5.0 (3.73) 7.6 9.5 15
40RM
40RMQ
40RMS
028
208/230-3-60 187-253 7.5 (5.59) 21.4/19.4 26.9/24.3 45/40
460-3-60 414-506 7.5 (5.59) 9.7 12.1 20
575-3-60 518-632 7.5 (5.59) 7.8 9.8 15
230-3-50 207-253 7.5 (5.59) 22.8 28.5 50
400-3-50 360-440 7.5 (5.59) 11.4 14.3 25
40RM
40RMS
034
208/230-3-60 187-253 10.0 (7.46) 28.2/26.8 35.3/33.5 60/60
460-3-60 414-506 10.0 (7.46) 13.4 16.8 30
575-3-60 518-632 10.0 (7.46) 10.3 12.9 20
230-3-50 207-253 10.0 (7.46) 32.2 40.3 70
400-3-50 360-440 10.0 (7.46) 16.1 20.1 30
