Table 19 —Defrosting Operation (For Heat Recovery Only)
Table 20 —Defrosting Operation (For Heat Pump and Single Phase VRF Only)
When receiving the signal for defrosting completion, the opening of the heating thermo-ON indoor unit is 240P for 500P-
Opening EEV and 960P for 2000P-EEV. It will remain like this for three minutes, and then go to normal control.
The thermo-OFF or fan mode indoor unit will recover standby or fan mode control after defrost completion.
Fig. 33 —Defrosting Operation
Fan Speed Setting in Cooling Thermo-OFF
This can be set from the wired remote controller. The default setting is holding on the current speed.
Fan Speed Setting in Heating Thermo-OFF
It is invalid for Heat Pump and Mini-VRF systems to set fan speed in heating thermo-OFF, but for Heat Recovery systems, it can
be set from the wired remote controller. The default setting is OFF.
BEFORE DEFROSTING
DEFROST OPERATING
2000P EEV 500P EEV
FAN
OPERATING MODE ENERGY DEMAND < 1 MIN [1,3] MIN ≥ 3 MIN < 1 MIN [1,3] MIN ≥ 3 MIN
Cooling Thermo-ON Cooling Not 0 800P 800P 1504P 120P 120P 300P Keep unchanged
Cooling Thermo-OFF Cooling 0 800P 800P 1504P 120P 120P 300P Keep unchanged
Heating Thermo-ON Heating Not 0 504P 800P 1504P 72P 120P 300P OFF
Heating Thermo-OFF Heating 0 504P 800P 1504P 72P 120P 300P OFF
OFF None 0 800P 800P 800P 120P 120P 120P OFF
Error -- 0 800P 800P 800P 120P 120P 120P OFF
Fan None 0 800P 800P 800P 120P 120P 120P Keep unchanged
BEFORE DEFROSTING
DEFROSTING OPERATING
2000P EEV 500P EEV
FAN
OPERATING MODE ENERGY DEMAND OPENING OPENING
Heating Thermo-ON Heating Not 0 1504P 480P OFF
Heating Thermo-OFF Heating 0 1504P 480P OFF
OFF None 0 1504P 480P OFF
Error -- 1504P 480P OFF
Tsh=55°F (Default) or
Tsc=85°F
62°F (ǻt=0 & ǻF=2°F)
