Carrier 40VM Series Service Manual

3
INDOOR UNITS
General Information
INDOOR UNIT MODEL NUMBER NOMENCLATURE
Fig. 1 —Model Nomenclature (Indoor Units)
Table 1 —Indoor Unit Capacity
INDOOR UNIT CAPACITY 5 7 9 12 15 18 24 30 36 48 54 72 96
4-Way Cassette 40VMF • • • • • • • •
Compact 4-Way Cassette 40VMC • • • • •
1-Way Cassette 40VMI • • • • • • •
High Wall 40VMW • • • • • • • •
Low Static Duct 40VML • • • • • •
Medium Static Duct 40VMM • • • • • • • • •
High Static Duct 40VMH • • • • • • •
Vertical AHU 40VMV • • • • • • •
Underceiling/Floor 40VMU • • • • • • •
Floor Console Recessed 40VMR • • • • • •
Outside Air 40VMA • • • • •
40 VM F 007 A - - 3
Digit # 1,2: Product Series
40 - Indoor Fan Coil Unit
Digit # 3,4: Model Letters
VM - Carrier VRF
Digit # 12: Electrical
3 - 208/230-1-60
Digit # 5: Model Number Modifier
A - Outside Air
C - Compact 4-Way Cassette Digit # 11: Not Defined
D - Multiport Distribution Controller - Blank
F - 4-Way Cassette
H - High Static Duct Digit # 10: Not Defined
L - Low Static Duct
- Blank
M - Medium Static Duct
Digit # 9: Not De
fined
R - Floor Console Recessed
A - Design Revision
U - Underceiling / Floor
V - Vertical AHU
W - High Wall
Digit # 6,7,8: Cooling Capacity (Btu/h)
009 - 9,000 012 - 12,000
015 - 15,000 018 - 18,000
024 - 24,000
030 - 30,000
036 - 36,000
048 - 48,000
I - 1-Way Cassette
005 - 5,000
007 - 7,000
054 - 54,000
072 - 72,000
096 - 96,000
