Carrier 40VM Series Service Manual

6
Table 3 —List of Electronic Expansion Valve Types
● 500 Pulses
☐ 2000 Pulses
Operating Temperature Range
The 40VMA (outside air) functions are cooling, heating, and fan operation.
Other indoor units can operate in cooling, heating, auto, fan, and dry mode.
COOLING MODE —
Indoor unit (except 40VMA) thermal OFF is activated when the return air temperature is below 59°F WB.
HEATING MODE —
Indoor unit (except 40VMA) thermal OFF is activated when return air temperature is above 84°F DB.
Table 4 —40VMC, F, H, I, L, M, R, U, V, W
Table 5 —40VMA
CAPACITY INDEX 5 7 9 12 15 18 24 30 36 48 54 72 96
1-Way Cassette (40VMI)
●
●
● ● ● ● ●
4-Way Cassette (40VMF) ● ● ● ● ● ● ● ●
High Wall (40VMW)
☐
☐ ☐ ☐ ☐ ☐ ☐ ☐
Medium Static Duct (40VMM)
☐ ☐ ☐ ☐ ☐
● ● ● ●
Low Static Duct (40VML)
☐ ☐ ☐ ☐ ☐ ☐
Vertical Air Handing Unit (40VMV) ● ● ● ● ● ● ●
High Static Duct (40VMH) ● ● ● ● ● ● ●
Outside air (40VMA) ● ● ● ● ●
Compact 4-Way Cassette (40VMC) ● ● ● ● ●
Underceiling/Floor (40VMU) ● ● ● ● ● ● ●
Floor Console Recessed (40VMR)
☐ ☐ ☐ ☐ ☐
Mode Inside Temperature
Cooling 50~75
°FWB
Heating 54~86°FDB
Mode Inside Temperature
Cooling and
Fan
41~109
°FWB
Heating 23~109°FDB
