NOTE: CFM values below recommended minimum may affect life of
motor.
Table 15 — 45K Size 3 — ECM Calibration
SET
POINT
CFM
VCU
MANUAL %
DISPLAY
(OPTION 6)
ACU-0
REMOTE 0-10VDC
(0-20mA)
DC SIGNAL
(OPTION 7)
ACU-P
REMOTE
2-10VDC
(4-20mA)
DC SIGNAL
(OPTION 8)
VDC mA VDC mA
1050 100 10.0 (20.0) 10.0 (20.0)
1040 99 9.9 (19.8) 9.9 (19.8)
1029 98 9.8 (19.6) 9.8 (19.7)
1019 97 9.7 (19.4) 9.8 (19.5)
1008 96 9.6 (19.2) 9.7 (19.4)
998 95 9.5 (19.0) 9.6 (19.2)
987 94 9.4 (18.8) 9.5 (19.0)
977 93 9.3 (18.6) 9.4 (18.9)
966 92 9.2 (18.4) 9.4 (18.7)
956 91 9.1 (18.2) 9.3 (18.6)
945 90 9.0 (18.0) 9.2 (18.4)
935 89 8.9 (17.8) 9.1 (18.2)
924 88 8.8 (17.6) 9.0 (18.1)
914 87 8.7 (17.4) 9.0 (17.9)
903 86 8.6 (17.2) 8.9 (17.8)
893 85 8.5 (17.0) 8.8 (17.6)
882 84 8.4 (16.8) 8.7 (17.4)
872 83 8.3 (16.6) 8.6 (17.3)
861 82 8.2 (16.4) 8.6 (17.1)
851 81 8.1 (16.2) 8.5 (17.0)
840 80 8.0 (16.0) 8.4 (16.8)
830 79 7.9 (15.8) 8.3 (16.6)
819 78 7.8 (15.6) 8.2 (16.5)
8.9 77 7.7 (15.4) 8.2 (16.3)
798 76 7.6 (15.2) 8.1 (16.2)
788 75 7.5 (15.0) 8.0 (16.0)
777 74 7.4 (14.8) 7.9 (15.8)
767 73 7.3 (14.6) 7.8 (15.7)
756 72 7.2 (14.2) 7.8 (15.5)
746 71 7.1 (14.0) 7.7 (15.4)
735 70 7.0 (13.8) 7.6 (15.2)
725 69 6.9 (13.6) 7.5 (15.0)
714 68 6.8 (13.6) 7.4 (14.9)
704 67 6.7 (13.4) 7.4 (14.7)
693 66 6.6 (13.2) 7.3 (14.6)
683 65 6.5 (13.0) 7.2 (14.4)
672 64 6.4 (12.8) 7.1 (14.2)
662 63 6.3 (12.6) 7.0 (14.1)
651 62 6.2 (12.4) 7.0 (13.9)
641 61 6.1 (12.2) 6.9 (13.8)
630 60 6.0 (12.0) 6.8 (13.6)
620 59 5.9 (11.8) 6.7 (13.4)
609 58 5.8 (11.6) 6.6 (13.3)
599 57 5.7 (11.4) 6.6 (13.1)
588 56 5.6 (11.2) 6.5 (13.0)
578 55 5.5 (11.0) 6.4 (12.8)
567 54 5.4 (10.8) 6.3 (12.6)
557 53 5.3 (10.6) 6.2 (12.5)
546 52 5.2 (10.4) 6.2 (12.3)
536 51 5.1 (10.2) 6.1 (12.2)
525 50 5.0 (10.0) 6.0 (12.0)
515 49 4.9 (9.8) 5.9 (11.8)
504 48 4.8 (9.6) 5.8 (11.7)
494 47 4.7 (9.4) 5.8 (11.5)
483 46 4.6 (9.2) 5.7 (11.4)
473 45 4.5 (9.0) 5.6 (11.2)
462 44 4.4 (8.8) 5.5 (11.0)
452 43 4.3 (8.6) 5.4 (10.9)
441 42 4.2 (8.4) 5.4 (10.7)
431 41 4.1 (8.2) 5.3 (10.6)
420 40 4.0 (8.0) 5.2 (10.4)
410 39 3.9 (7.8) 5.1 (10.2)
399 38 3.8 (7.6) 5.0 (10.1)
389 37 3.7 (7.4) 5.0 (9.9)
378 36 3.6 (7.2) 4.9 (9.8)
368 35 3.5 (7.0) 4.8 (9.6)
357 34 3.4 (6.8) 4.7 (9.4)
347 33 3.3 (6.6) 4.6 (9.3)
336 32 3.2 (6.4) 4.6 (9.1)
326 31 3.1 (6.2) 4.5 (9.0)
315 30 3.0 (6.0) 4.4 (8.8)
305 29 2.9 (5.8) 4.2 (8.6)
294 28 2.8 (5.6) 4.2 (8.5)
284 27 2.7 (5.4) 4.1 (8.3)
273 26 2.6 (5.2) 4.0 (8.2)
263 25 2.5 (5.0) 3.9 (8.0)
252 24 2.4 (4.8) 3.8 (7.8)
242 23 2.3 (4.6) 3.8 (7.7)
231 22 2.2 (4.4) 3.6 (7.5)
221 21 2.1 (4.2) 3.7 (7.4)
210 20 2.0 (4.0) 3.6 (7.2)
200 19 1.9 (3.8) 3.5 (7.0)
189 18 1.8 (3.6) 3.4 (6.9)
179 17 1.7 (3.4) 3.4 (6.7)
168 16 1.6 (3.2) 3.3 (6.6)
158 15 1.5 (3.0) 3.2 (6.4)
147 14 1.4 (2.8) 3.1 (6.2)
137 13 1.3 (2.6) 3.0 (6.1)
126 12 1.2 (2.4) 3.0 (5.9)
116 11 1.1 (2.2) 2.9 (5.8)
105 10 1.0 (2.0) 2.8 (5.6)
95 9 0.9 (1.8) 2.7 (5.4)
84 8 0.8 (1.6) 2.6 (5.3)
74 7 0.7 (1.4) 2.6 (5.1)
63 6 0.6 (1.2) 2.5 (5.0)
53 5 0.5 (1.0) 2.4 (4.8)
42 4 0.4 (0.8) 2.3 (4.6)
32 3 0.3 (0.6) 2.2 (4.5)
21 2 0.2 (0.4) 2.2 (4.3)
11 1 0.1 (0.2) 2.1 (4.2)
Table 15 — 45K Size 3 — ECM Calibration (cont)
SET
POINT
CFM
VCU
MANUAL %
DISPLAY
(OPTION 6)
ACU-0
REMOTE 0-10VDC
(0-20mA)
DC SIGNAL
(OPTION 7)
ACU-P
REMOTE
2-10VDC
(4-20mA)
DC SIGNAL
(OPTION 8)
VDC mA VDC mA
