19.2. Air quality probe 4.. 20 mA
Installation in the environment
Duct-mounted
M16x1,5
Ø > 13mm
Ø > 0.51“
19mm
0.75“
90
±0.3
mm
3.54
±0.11
“
5mm
0.2“
60
±0.3
mm
2.36
±0.11
“
Ø > 16mm
Ø > 0.63“
6mm
0.24“
Electrical connection
Cleaning and maintenance
19 - TECHNICAL AND ELECTRICAL CHARACTERISTICS
Assembly and setting instructions
+V
GND
RH
T
CO2
GND
1
2
3
4
5
6
110
111
109
B10 (J18)
S10
Electric
panel
+V
GND
GND
CO2
NC
Tpassive
Tpassive
1
2
3
4
5
6
7
110
111
109
B10 (J18)
S10
Electric
panel
Environment: Duct-mounted:
