Carrier 58MVB Series - Horizontal Installation Examples; Attic Horizontal Application; Crawlspace Horizontal Application

21
COMBUSTION–AIR PIPE
ELECTRONIC
AIR CLEANER
FURNACE
CONDENSATE
DRAIN
REFRIGERATION
PIPING
AIR CONDITIONING
COIL
AIRFLOW
VENT PIPE
FRONT OF FURNACE
A05066
DIRECT VENT/2-PIPE APPLICATION)
COMBUSTION-AIR INLET
(NON-DIRECT VENT/1-PIPE APPLICATION)
Attic — Horizontal Application A05066
Crawlspace — Horizontal Application A05067
COMBUSTION– AIR PIPE
(DIRECT VENT/2-PIPE
APPLICATION)
VENT
PIPE
ELECTRONIC
AIR CLEANER
FURNACE CONDENSATE
DRAIN
AIRFLOW
AIR CONDITIONING
COIL
REFRIGERATION
PIPING
FRONT OF
FURNACE
A05067
COMBUSTION - AIR INLET
(NON-DIRECT VENT/
1-PIPE APPLICATION)
