Carrier 58MVB Series User Manual

4
Model number nomenclature
Carrier accessories *
See notes at end of table.
UNIT SIZE 040-14 060-14 080-14 080-20 100-20 120-20
VENT TERMINATION KIT (Bracket Only for 2 Pipes)
2-in. — KGAVT0101BRA
3-in. — KGAVT0201BRA
XXXXXX
CONCENTRIC TERMINATION KIT (Single Exit)
2-in. — KGAVT0501CVT
3-in. — KGAVT0601CVT
XXXXXX
CONDENSATE FREEZE PROTECTION KIT KGAHT0101CFP
XXXXXX
CONDENSATE NEUTRALIZER KIT (obtained thru RCD) P908-0001
XXXXXX
ELECTRONIC AIR CLEANER (EAC)‡ Model EACA
XXXXXX
MECHANICAL AIR CLEANER Model FILCAB OR EZXCAB
XXXXXX
HUMIDIFIER Model HUM
XXXXXX
HEAT RECOVERY VENTILATOR Model HRV
XXXXXX
ENERGY RECOVERY VENTILATOR Model ERV
XXXXXX
UV LIGHTS Model UVL
XXXXXX
EZ FLEX MEDIA FILTER WITH END
CAPS – 16 IN. (9 pack)
EXPXXLMC0016 X
EZ FLEX MEDIA FILTER WITH END
CAPS – 20 IN. (9 pack)
EXPXXLMC0020 X X X
EZ FLEX MEDIA FILTER WITH END
CAPS – 24 IN. (6 pack)
EXPXXLMC0024 X X
REPLACEMENT EZ FLEX FILTER – 16 IN. (10 pack)
EXPXXFIL0016 X
REPLACEMENT EZ FLEX FILTER – 20 IN. (10 pack)
EXPXXFIL0020 X X X
REPLACEMENT EZ FLEX FILTER – 24 IN. (10 pack)
EXPXXFIL0024 X X
EXTERIOR FILTER RACK – UNIVERSAL, ONE INCH
(adjustable from 14" to 24") with filter
KGAFR0301ALL
KGAFR0306ALL
(6-pack)
XXXXX
UNFRAMED FILTER, ONE INCH – 16X25
KGAWF1301UFR
KGAWF1306UFR
(6-pack)
SXSSS
UNFRAMED FILTER, ONE INCH – 20X25
KGAWF1401UFR
KGAWF1406UFR
(6 pack)
XXX
UNFRAMED FILTER, ONE INCH – 24X25
KGAWF1501UFR
KGAWF1506UFR
(6 pack)
XX
COMBUSTIBLE FLOOR BASE (not
required when evaporator coil case is used)
KGASB0201ALL X X X X X
NATURAL-TO-PROPANE GAS
CONVERSION KIT (Single Kit)*
KGANP4001ALL
XXXXXX
PROPANE-TO-NATURAL GAS
CONVERSION KIT (Single Kit)
KGAPN3301ALL
XXXXXX
ECM MOTOR SIMULATOR (replaces the ECM motor
to aid trouble shooting)
KGASD0201FMS X X X X X X
DOOR GASKET KIT KGBAC0110DGK
XXXXXX
58MVB 040
Deluxe 4-Way Multipoise
Variable-Speed Direct-Vent (2-Pipe) and
Non-Direct Vent (1-Pipe) Condensing Gas
Furnace
Input Rates
040 — 40,000 Btuh
060 — 60,000 Btuh
080 — 80,000 Btuh
100 — 100,000 Btuh
120 — 120,000 Btuh
F 100 08
Cooling Airflow
(400 CFM per
12,000 Btuh)
14 — 1400 CFM
20 — 2000 CFM
Series
Media Filter Cabinet included

Carrier 58MVB Series Specifications

General

Blower Motor	Variable-speed
Gas Valve	Modulating
Ignition System	Hot Surface Ignition
Fuel Type	Natural gas
Heating Capacity	40, 000 to 120, 000 BTU/h
Warranty	10-year parts limited warranty upon registration
