WEB AND NETWORK INTERFACE
The Carrier Controller control can be configured to allow access
via a standard, java-enabled web browser or over a network. See
Appendix I for detailed information on setting up and accessing
the Carrier Controller via the web or network interface. See Table
5 for port connections. See Fig. 18 for interface and connectors.
Table 5 — Carrier Controller Display Port
Connections
NOTES:
1. For more information about password access, see Carrier Control-
ler Login and Display Setup on page 9.
2. PINOUT is listed as viewed from back of from left to right on
connector.
CONNECTOR
TYPE/
PINOUT
FUNCTION
J1 TYPE-A USB-3: Firmware/Software Upgrade
J5 TYPE-A USB-1: Firmware/Software Upgrade
J6
+
RS485-1: LEN System Internal
I/O Boards
C
-
J7
+
RS485-2: CCNC
-
J8
-
RS485-4: BMS Interface, BACnet
SHD
C
+
J9
12V
RNET Port to Support RNET Devices
-
+
G
J10
-
RS485-3: Not used
SHD
C
+
J11 TYPE-A USB-2: Firmware/Software Upgrade
J14
G
24VAC Power
+
J15 RJ45
Ethernet-2: Service Tool, BMS Interface,
BACnet, WAN (connectivity)
J16 RJ45 Ethernet-1: WAN (connectivity)
