14
Standard unit + option 15 + high-
pressure dual-pump hydronic module
option
kg 1896 2006 2093 2118 2292 2911 3102 3258 3358 3720 3977 4183 - - - -
Unit with option 15 kg 1720 1830 1917 1934 2108 2606 2797 2913 3013 3375 3582 3768 4828 5091 5597 5861
Standard unit** kg 1645 1755 1842 1839 2013 2489 2680 2779 2879 3224 3431 3600 4627 4873 5362 5609
Sound power level 10
-12
W*** dB(A) 84 84 84 85 85 86 86 87 87 88 88 88 89 89 89 90
Sound pressure level 10 m distance**** dB(A) 52 52 52 53 53 54 54 55 55 55 55 56 56 57 57 57
Sound power level 10
-12
W*** dB(A) 89 89 89 89 89 90 90 91 91 92 92 92 93 93 94 94
Sound pressure level 10 m distance**** dB(A) 57 57 57 57 57 58 58 59 59 60 60 60 61 61 61 62
Sound power level 10
-12
W*** dB(A) 91 91 91 91 91 92 92 93 93 94 94 94 95 95 96 96
Sound pressure level 10 m distance**** dB(A) 59 59 59 59 59 60 60 61 61 62 62 62 62 63 63 64
Hermetic scroll, 48.3 r/s
Circuit A 1 1 1 2 2 3 3 3 3 4 4 4 3 3 4 4
Circuit B 2 2 2 2 2 2 2 3 3 3 3 4 3 3 4 4
Circuit C - - - - - - - - - - - - 3 4 3 4
No. of control stages - - - - 4 5 5 6 6 7 7 8 9 10 11 12
R-410A
Circuit A kg 9.2 11 11 13.5 13.5 18.5 19.5 19.5 19 24.3 24.5 24.5 21.5 21.5 26 26
Circuit B kg 12.8 12.8 12.8 13 13 13 14 19.5 20 21.5 21.5 25.5 22 21.5 28 28
Circuit C kg - - - - - - - - - - - - 23.5 28 24 31
Pro-Dialog Plus
Minimum capacity % 33 28 33 25 25 18 20 15 17 13 14 13 11 10 9 8
All aluminium micro-channel heat exchanger (MCHX)
Axial Flying Bird 4 with rotating shroud
Quantity 3 4 4 4 4 5 5 6 6 7 7 8 9 10 11 12
Total air ow l/s 13542 18056 18056 18056 18056 22569 22569 27083 27083 31597 31597 36111 40623 45139 49653 54167
Speed r/s 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16
Direct expansion, shell-and-tube
Water volume l 110
110 110 110 110 110 125 125 125 113 113 113 284 284 284 284
Max. water-side operating pressure
without hydronic module
kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Pump, Victaulic screen lter, safety valve, expansion tank, pressure gauge, water + air purge valves, ow control valve
Water pump Centrifugal, monocell, low or high pressure (as required), 48.3 r/s, single or twinned dual pump (as required)
Quantity 1 1 1 1 1 1 1 1 1 1 1 1 - - - -
Expansion tank volume l 50 50 50 50 50 80 80 80 80 80 80 80 - - - -
Max. water-side operating pressure
with hydronic module
kPa 400 400 400 400 400 400 400 400 400 400 400 400 - - - -
Victaulic
Diameter inch 3 3 3 3 3 4 4 4 4 6 6 6 6 6 6 6
Outside tube diameter mm 88.9 88.9 88.9 88.9 88.9 114.3 114.3 114.3 114.3 168.3 168.3 168.3 168.3 168.3 168.3 168.3
Victaulic
Diameter inch 3 3 3 3 3 4 4 4 4 5 5 5 - - - -
Outside tube diameter mm 88.9 88.9 88.9 88.9 88.9 114.3 114.3 114.3 114.3 139.7 139.7 139.7 - - - -
Colour code: RAL 7035
* Weight shown is a guideline only. To nd out the unit refrigerant charge, please refer to the unit nameplate.
** Standard unit = base unit without option 15 and hydronic module option.
*** In accordance with ISO 9614-1 and certied by Eurovent.
**** For information, calculated from the sound power level Lw(A).
