16
The pumps that are factory-installed in these units have
motors with efficiency class IE2. The additional electrical
data required* is as follows:
Motors of single and dual low-pressure pumps for 30RB162-262 B standard units (options 116F, 116G, 116P, 116Q)
1 Nominal eciency at full load and nominal voltage % 83.4 83.4 83.4 83.4 84.8
1 Nominal eciency at 75% rated load and nominal voltage % 82.9 82.9 82.9 82.9 84.5
1 Nominal eciency at 50% rated load and nominal voltage % 80.4 80.4 80.4 80.4 83.1
2 Eciency level IE2
3 Year of manufacture This information varies depending on the manufacturer and model at the time of
incorporation. Please refer to the motor name plates.
4 Manufacturer's name and trademark, commercial
registration number and place of manufacturer
5 Product's model number
6 Number of motor poles 2 2 2 2 2
7-1 Rated shaft power output at full load and nominal voltage
(400 V)
kW 2.2 2.2 2.2 2.2 3
7-2 Maximum power input (400 V)**** kW 2.6 2.6 2.6 2.6 3.5
8 Rated input frequency Hz 50 50 50 50 50
9-1 Rated voltage V 3 x 400
9-2 Maximum current drawn (400 V)† A 4.4 4.4 4.4 4.4 5.8
10 Rated speed r/s (rpm) 48 (2900)
11 Product disassembly, recycling or disposal at end of life Disassembly using standard tools. Disposal and recycling using an appropriate company.
12 Operating conditions for which the motor is specically designed
I - Altitudes above sea level m < 1000††
II - Ambient air temperature °C < 40
IV - Maximum air temperature Please refer to the operating conditions given in this manual or in the specic conditions in
the Carrier selection programs.
V - Potentially explosive atmospheres Non-ATEX environment
Motors of single and dual low-pressure pumps for 30RB 162-262 B units with option 280 and 30RB 302-522 units
(options 116F, 116G, 116P, 116Q)
1 Nominal eciency at full load and nominal voltage % 83.4 83.4 83.4 83.4 83.4 84.8 84.8 86.1 86.1 86.1 88.6 88.6
1 Nominal eciency at 75% rated load and nominal voltage % 82.9 82.9 82.9 82.9 82.9 84.5 84.5 85.7 85.7 85.7 86.9 86.9
1 Nominal eciency at 50% rated load and nominal voltage % 80.4 80.4 80.4 80.4 80.4 83.1 83.1 84.3 84.3 84.3 85.2 85.2
2 Eciency level IE2
3 Year of manufacture This information varies depending on the manufacturer and model at the time of
incorporation. Please refer to the motor name plates.
4 Manufacturer's name and trademark, commercial
registration number and place of manufacturer
5 Product's model number
6 Number of motor poles 2 2 2 2 2 2 2 2 2 2 2 2
7-1 Rated shaft power output at full load and nominal voltage
(400 V)
kW 2.2 2.2 2.2 2.2 2.2 3 3 4 4 4 5.5 5.5
7-2 Maximum power input (400 V)**** kW 2.6 2.6 2.6 2.6 2.6 3.5 3.5 4.6 4.6 4.6 6.2 6.2
8 Rated input frequency Hz 50 50 50 50 50 50 50 50 50 50 50 50
9-1 Rated voltage V 3 x 400
9-2 Maximum current drawn (400 V)† A 4.4 4.4 4.4 4.4 4.4 5.8 5.8 7.7 7.7 7.7 10.2 10.2
10 Rated speed r/s (rpm) 48 (2900)
11 Product disassembly, recycling or disposal at end of life Disassembly using standard tools. Disposal and recycling using an appropriate company
12 Operating conditions for which the motor is specically designed
I - Altitudes above sea level m < 1000††
II - Ambient air temperature °C < 40
IV - Maximum air temperature Please refer to the operating conditions given in this manual or in the specic conditions in
the Carrier selection programs.
V - Potentially explosive atmospheres Non-ATEX environment
* Required by regulation 640/2009 with regard to the application of directive 2005/32/EC on the eco-design requirements for electric motors
** Item number imposed by regulation 640/2009, annex I2b.
*** Description given by regulation 640/2009, annex I2b.
**** To obtain the maximum power input for a unit with hydronic module add the maximum unit power input from the electrical data table to the pump power input.
† To obtain the maximum unit operating current draw for a unit with hydronic module add the maximum unit current draw from the electrical data table to the pump current
draw.
†† Above 1000 m, a degradation of 3% for each 500 m should be taken into consideration.
