43
11.3.1 - Physical data, 30RB units with partial heat reclaim using desuperheaters (option 49)
Standard unit** kg 1882 1974 2074 2092 2260 2853 3049 3092 3218 3755 3895 4063 5285 5484 6145 6315
Unit with options*** kg 2052 2154 2244 2282 2450 3083 3279 3342 3478 4045 4185 4373 5645 5833 6555 6745
Unit with options**** kg 2302 2404 2484 2522 2690 3393 3589 3692 3818 4395 4585 4795 - - - -
Plate heat exchangers
Water volume circuit A l 1.75 1.75 1.75 3.75 3.75 5.5 5.5 5.5 5.5 7.5 7.5 7.5 5.5 5.5 7.5 7.5
Water volume circuit B l 3.5 3.5 3.5 3.75 3.75 3.75 3.75 5.5 5.5 5.5 5.5 7.5 5.5 5.5 7.5 7.5
Water volume circuit C l - - - - - - - - - - - - 5.5 7.5 5.5 7.5
Max. water-side operating pressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Cylindrical, male gas thread
Connection in 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Outside diameter mm 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3 60.3
* Weights shown are a guideline only
** Standard unit (with MCHX coils) and desuperheater option
*** Unit with option 15 + desuperheater
**** Unit with option 15 + desuperheater + hydronic module with high-pressure dual pump
This option permits the production of free hot water using
heat reclaim by desuperheating the compressor discharge
gases. The option is available for the whole 30RB range.
A plate heat exchanger is installed in series with the air con-
denser coils on the compressor discharge line of each circuit.
The control configuration for the desuperheater option is
factory assembled (see chapter 11.3.6 - Control configura-
tion).
