Carrier CCU - Temperature Source Details and Bus Configuration; 6.1.3 Reading Parameters Overview; Monitoring Measured Values and Logic States

Access level No. Description Setting By default Display condition
CONTROLLED TEMPERATURE ORIGIN SELECTION
2 209 Low temperature (2 V) -40,0 to 99,9 °C -20,0 °C
(P07 > 0 or P08 > 0) and P207 = 2
2 210 High temperature (10 V) -40,0 to 99,9 °C 80,0 °C (P07 > 0 or P08 > 0) and P207 = 2
2 211
Cooling temperature setpoint with
2-10 V sensor fault
8,0 to 45,0 if P08 > 0 25,0 °C P07 > 0 and P207 = 2
2 212
Heating temperature setpoint with
2-10 V sensor fault
MAX (8,P212) to 45,0 °C if P07>0 20,0 °C P08 > 0 and P207 = 2
MASTER/SLAVE BUS
2 215 Unit number on console 1 to 32 1
6.1.3 - Reading parameters (sub-menu 3.3)
This third sub-menu gives access to all the values (temperatures, relative humidities, pressures, time delays, meters, input and output
states, etc.) managed by the CCU CONTROLLER.. Only the useful parameters are displayed. They cannot be modied
The meters can be reset to zero. To do this, place the cursor on the chosen meter and simultaneously press the Reset and 0 keys for
5 to 6 seconds.
All these parameters are accessible from the "customer" access level.
Access level No. Description Unit Display condition
CALCULATED SETPOINT
1 250 Cooling setpoint value °C P07 > 0
1 251 Temperature setpoint value in heating mode °C P08 > 0
1 252 Air ow activation threshold value Pa P02 ≠ 17
1 253 Filter fouling activation threshold value Pa
1 254 Filter clogging activation threshold value Pa
MEASURED VALUE
1 255 Target temperature °C P07 > 0 or P08 > 0
1 256 Target relative humidity % P09 > 0 or P10 > 0
1 257 Filter di󰀨erential pressure Pa
1 258 Outdoor temperature °C P11 = 1
1 259 Supply air temperature °C P06 = 1
1 265 Outdoor humidity %
(P09 > 0 or P10 > 0) and P11 = 1
1 266 Raised oor di󰀨erential pressure Pa P2 = 16
1 267 Fan 1 di󰀨erential pressure Pa P02 = 17
1 268 External weight in water g/Kg (P09>0 or P10>0) and P11=1
1 269 Air ow rate m³/h P02 = 17
LOGIC INPUT STATE (ON/OFF)
1 270 Electric heater safety thermostat with manual reset default = o󰀨
1 271 Summary of condensation unit 1 faults default = on P17 > 5
1 272 Summary of condensation unit 2 faults default = on P17 > 6
1 278 External safety contact
1 279 On request contact
1 281 Humidier maintenance, fault or operation feedback default = o󰀨 P10 = 1
1 282 Fan operation feedback default = o󰀨
1 284 Water leak contact default = o󰀨
1 287 Hot water coil or electric heater selection contact
electric o󰀨
hot water on
P08 = 3
1 288 Summer or winter mode contact
summer o󰀨
winter on
P19 = 1
