13.2 - Conguring the communication bus parameters (menu 7)
This menu gives access to all parameters used to dene the communication protocol and the 2-wire RS485 serial link parameters.
Access level No. Description Setting By default Display condition
2 700 Communication mode 1: MODBUS/JBUS 1
2 701 Communication speed
0: 4800 bauds
1: 9600 bauds
2: 19200 bauds
1
2 702 Parity
0: None
1: Even
2: Odd
0
2 703 Number of stop bits
1: stop bit
2: stop bits
1
2 704 Actual number format reversed
0: No
1: Yes
0
2 705 Slave number 1 to 255 1
2 706 Control type*
1: Local
2: Remote
1
*  If the selected control type is local, the controller data can be accessed in read-only mode by the PLC; with remote selection, the controller data can be accessed in 
read and write mode by the PLC.
13.3 - ModBus protocol
RS485 2-wire communication support
3-pin connector (J10) 
Terminal 1: A or +
Terminal 2: B or –
Terminal 3: 0 V 
Line termination resistor: Connected if COM1 is ON
Not connected if COM1 is OFF
External BUS polarisation. 
Transmission mode
Series, asynchronous, half duplex, one start bit, eight data bits, 
Parity congured by P702 (none, odd or even) 
Number of stop bits congured by P703 (1 stop bit or 2 stop bits) 
Communication speed congured by P701 (4800, 9600 or 19200) 
Slave no. on the bus congured by P705 
Protocol
ModBus (Gould Modicon) 
Compatible: JBUS (Merlin Gerin) 
RTU (GENERAL ELECTRIC protocol) 
Codes of functions used
1 or 2: read n bits 
3 or 4: Read multiple registers (16 bits) Maximum of 126 registers read 
5: Write one bit 
• 6: Write one register
• 8: Read diagnostic counter
11: Read event counter 
15: Write n bits 
16: Write multiple registers (16 bits) 
Analogue value encoding
Standard 32-bit IEEE format (2 registers). 
The byte order can be reversed with P704 (0:not reversed or 1:reversed) 
NOTE: the register numbers correspond to the addresses coded on 16 bits. 
Register denitions
Function 3 or 4 is used for reading, 
• Function 6 or 16 is used for writing.
