Table 6A — Unit Electrical Data, 30HXC Units
UNIT
30HXC
UNIT VOLTAGE
POWER
SUPPLY
QTY. REQD.
NO. POWER
SUPPLY
CONDUCTORS
UNIT VOLTAGE CONTROL CIRCUIT
V-Hz
(3 Ph)
Supplied
MCA MOCP
ICF Rec Fuse Size V-Hz
(Single
Ph)
Supplied MCA
and
MOCP
Min Max XL WD XL WD Min Max
076
230-60 207 253 1 3 198.7 250 — 297.3 — 225 115-60 104 127 15
208/230-60 187 253 1 3 220.7 300 — 307.1 — 250 115-60 104 127 15
460-60 414 506 1 3 99.7 125 374.3 148.3 125 125 115-60 104 127 15
575-60 518 633 1 3 79.7 110 299.4 118.4 90 90 115-60 104 127 15
380-60 342 418 1 3 120.8 150 418.7 168.7 150 150 230-60 207 254 15
380/415-50 342 440 1 3 125.6 175 399.8 164.8 150 150 230-50 198 254 15
230-50 207 253 1 3 207.2 250 — 266.1 — 250 230-50 207 254 15
086
230-60 207 253 1 3 221.7 300 — 297.3 — 250 115-60 104 127 15
208/230-60 187 253 1 3 246.4 350 — 307.1 — 300 115-60 104 127 15
460-60 414 506 1 3 111.3 150 374.3 148.3 125 125 115-60 104 127 15
575-60 518 633 1 3 88.9 125 299.4 118.4 100 100 115-60 104 127 15
380-60 342 418 1 3 134.8 175 418.7 168.7 175 175 230-60 207 254 15
380/415-50 342 440 1 3 140.4 200 478.8 189.8 175 175 230-50 198 254 15
230-50 207 253 1 3 231.9 300 — 305.1 — 300 230-50 207 254 15
096
230-60 207 253 1 3 251.3 350 — 344.3 — 300 115-60 104 127 15
208/230-60 187 253 1 3 279.2 400 — 354.1 — 350 115-60 104 127 15
460-60 414 506 1 3 126.2 175 449.3 172.3 150 150 115-60 104 127 15
575-60 518 633 1 3 100.8 150 359.4 137.4 125 125 115-60 104 127 15
380-60 342 418 1 3 152.7 225 501.7 194.7 175 175 230-60 207 254 15
380/415-50 342 440 1 3 157.9 225 561.8 215.8 200 200 230-50 198 254 15
230-50 207 253 1 3 260.7 350 — 347.1 — 300 230-50 207 254 15
106
230-60 207 253 1 3 285.6 400 — 395.3 — 350 115-60 104 127 15
208/230-60 187 253 1 3 317.4 450 — 405.1 — 400 115-60 104 127 15
460-60 414 506 1 3 143.3 200 529.3 197.3 175 175 115-60 104 127 15
575-60 518 633 1 3 114.5 175 423.4 158.4 150 150 115-60 104 127 15
380-60 342 418 1 3 173.6 250 589.7 222.7 200 200 230-60 207 254 15
380/415-50 342 440 1 3 178.1 250 660.8 246.8 225 225 230-50 198 254 15
230-50 207 253 1 3 294.2 450 — 397.1 — 350 230-50 207 254 15
116
230-60 207 253 1 3 304.1 450 — 413.7 — 350 115-60 104 127 15
208/230-60 187 253 1 3 337.9 500 — 425.6 — 400 115-60 104 127 15
460-60 414 506 1 3 152.6 225 538.6 206.6 175 175 115-60 104 127 15
575-60 518 633 1 3 121.9 175 430.8 165.8 150 150 115-60 104 127 15
380-60 342 418 1 3 184.8 250 600.9 233.9 225 225 230-60 207 254 15
380/415-50 342 440 1 3 190.0 250 672.7 258.7 225 225 230-50 198 254 15
230-50 207 253 1 3 313.9 450 — 416.8 — 400 230-50 207 254 15
126
230-60 207 253 1 3 327.7 450 — 437.4 — 400 115-60 104 127 15
208/230-60 187 253 1 3 364.2 500 — 451.9 — 450 115-60 104 127 15
460-60 414 506 1 3 164.5 225 550.5 218.5 200 200 115-60 104 127 15
575-60 518 633 1 3 131.4 175 440.3 175.3 150 150 115-60 104 127 15
380-60 342 418 1 3 199.1 250 615.2 248.2 225 225 230-60 207 254 15
380/415-50 342 440 1 3 204.0 300 686.7 272.7 250 250 230-50 198 254 15
230-50 207 253 1 3 337.0 450 — 439.9 — 400 230-50 207 254 15
136
230-60 207 253 1 3 366.7 500 — 497.4 — 450 115-60 104 127 15
208/230-60 187 253 1 6 407.4 600 — 511.9 — 500 115-60 104 127 15
460-60 414 506 1 3 183.8 250 645.5 248.5 225 225 115-60 104 127 15
575-60 518 633 1 3 147.1 200 536.3 199.3 175 175 115-60 104 127 15
380-60 342 418 1 3 222.8 300 720.2 282.2 300 300 230-60 207 254 15
380/415-50 342 440 1 3 230.2 300 796.7 307.7 300 300 230-50 198 254 15
230-50 207 253 1 6 380.3 500 — 495.9 — 450 230-50 207 254 15
146
230-60 207 253 1 6 394.1 500 — 524.9 — 450 115-60 104 127 15
208/230-60 187 253 1 6 437.9 600 — 542.4 — 500 115-60 104 127 15
460-60 414 506 1 3 197.5 250 659.2 262.2 225 225 115-60 104 127 15
575-60 518 633 1 3 158.1 225 547.3 210.3 200 200 115-60 104 127 15
380-60 342 418 1 3 239.5 350 736.9 298.9 300 300 230-60 207 254 15
380/415-50 342 440 1 3 246.3 350 812.8 323.8 300 300 230-50 198 254 15
230-50 207 253 1 6 407.1 600 — 522.7 — 500 230-50 207 254 15
