4
3.
FREMGANGSMÅDE VED INSTALLATION
1.
Betjeningspanelets dimensioner
Figur 3-1
2. Principtegning for ledningsføring:
Figur 3-2
18,5 mm
(0,7”)
83,5
4-kernet, armeret kabel, længden
afhænger af installationen
Indendørs fordelerskab
Tilslutning til fordelerskab
CN40
Betjeningspanel med ledning
rød
sort
gul
brun
rød
sort
gul
brun
120 mm
(4,7”)
46 mm
(1,8”)
83,5 mm
(3,3”)
123 mm
(4,8”)
62 mm
(2,4”)
D A
