Page 10 of 16 SC-409-10 Installation and Operating Instructions
11/10/05 CP4958A
Set Lever Switch and Auxiliary Switch Combination (Lever Switch in Position 1, 2, or 3).
1. Set the lever switch to desired position to program.
2. Press the desired auxiliary switch to change color to RED and tie it to the lever switch posi-
tion Press the auxiliary switch to change color to GREEN and remove from combination.
Note: The Timed Momentary (Gun Lock Timer) may not be added to combination.
Lever Switch and Auxiliary Switch Combination Programming Example
Resulting Operation as Lever Switch is moved to different positions
Save program and get out of program mode.
1. Once the switches are programmed as desired, save the program and exit programming
mode by turning SWB-3 (PGM) DIP switch OFF. Should hear two beeps sound confirming
the program is saved.
2. Turn unit off (backlight LEDS and Auxiliary Control Switches dark).
3. Detach the 12-P plug from the back of the unit to prevent shorting while installing cover.
4. Re-install the case cover and two screws at the bottom rear corners of the unit.
5. Re-attach the 12-P plug onto the back of the unit.
6. Re-attach the 6-P plug onto the back of the unit.
7. Programming is finished.
Note: If the unit is turned off before the SWB-3 (PGM) DIP switch is turned OFF, the new pro-
gramming will not be saved.
Lever
Position
Aux 1 Aux 2 Aux 3 Aux 4 Aux 5
Aux 6
Gun Lock
1 Red Green Green Green Green N/A Green
2 Red Red Red Green Green N/A Green
3 Red Green Red Green Green N/A Green
Lever
Position
Aux 1 Aux 2 Aux 3 Aux 4 Aux 5
Aux 6
Gun Lock
OFF Off Off Off No Change No Change No Change
1 On Off Off No Change No Change No Change
2 On On On No Change No Change No Change
3 On Off On No Change No Change No Change
