Page 6 of 16 SC-409-10 Installation and Operating Instructions
11/10/05 CP4958A
AMPLIFIER CONNECTIONS
NEG NEG
VID
ENA AUX
RAD RAD
CUT
POS POS
SPK SPK
RAD
VOL
SIREN
FUSE
SW6 SW5 SW4 SW3 SW2 SW1
LV3 LV2 LV1
BAT
-
+
RADIO
Plug installed
this orientation
12-P Terminal Block Plug
(CP4688-12)
#14 AWG BLK
Use second lead
for dual speaker
#14 AWG RED
Use second lead
for dual speaker
+ +
(2) #18 AWG BRN
(#16 AWG dual speaker)
dual speaker connect + to +
(2) #22 AWG BLU
Connect to output jack, ter-
minals, or speaker of radio
CAMERA
#22 AWG YEL
Connect to camera input
#22 AWG ORG
Unit Enable (like an ON/OFF switch)
Connect to positive circuit (fuse panel)
controlled by ignition or other switch
+VDC Switching examples
HORN
RING
SWITCH
+VDC
AUX
SPLICE
HORN
RING
SWITCH
+VDC
AUX
Added
SPDT
Switch
HORN
HORN
-VDC
switching
example
Must set AUX_P
option switch
MOMENTARY
FOOT
SWITCH
AUX
-VDC
switching
example
Must set CUT_P
option switch
ADDED
DOOR
SWITCH
CUT
+VDC Switching
example
DOOR
SWITCH
+VDC
CUT
SPLICE
DOME
LIGHT
#22 AWG
WHT
#22 AWG GRN
20A Automotive
Type Fuse
